Light DSV DP1 (<500 GT)
Unique light DSV for ROV operations. Previously long term operations for MoD. Location: Europe. Enquire
| General | |
| Re-built | 1997 – 2010 |
| Class | BV, I • Hull • Mach Special service |
| support vessel, Unlimited Navigation, | |
| • Dynapos AM / AT (DP1) | |
| Dimensions | |
| Length | 46 m |
| Beam | 11.5 m |
| Depth | 4.45 m |
| Draft | 2.3 m (light) / 3.0 m (max) |
| GT | 498 |
| Performance | |
| Max speed | 15 knots |
| Cruising speed | 12.5 knots |
| Range | 3,000 nm (service speed) |
| Fuel consumption | 4 m3/day (Service speed) |
| Clear deck space | 300 m2 |
| Machinery | |
| Main engine | 2 x 1500 kW |
| Propulsion | 2 x ASD |
| Bow thruster | 1 x 1,5 t |
| Generators | 2 x 230 kW |
| Aux. Generator | 1 x 100 kVA |
| Deck equipment | |
| Crane #1 | 2.3 t @ 11.8 m |
| Crane #2 | 0.8 t @ 10.5 m |
| A-frame | 17 t |
| Winch | Double drum 12,8 t |
| Wires | 600 m x 18 mm, 30 m x 20 mm |
| Other | ROV, USBL, Sonar |
| Tank Capacities | |
| Fuel | 87 m3 |
| Fresh water | 8.0 m3, 0.2 m3/h prod |
| Navigation & Communication | |
| DP system | DP1 |
| Other | MRU 2, Autopilot, Radar, 4 x GPS, |
| 2 x Gyro, Echosounder, Navtex, SART | |
| GMDSS | A3 |
| Accommodation | |
| Cabins | 4 x 1-berth, 4 x 2-berth, 2 x 3-berth |
| Other | Mess, galley, sanitary |
