3800 DWT shallow draft oil tanker (3 sisters)
1984, RMRS class, 3800 DWT, L x b x d x draft (m): 123 m x 15.3 x 5.3 x 3.5. Double hull, Location: Black Sea / Volga-Don channel. Enquire
| General | |
| Built | 1984 |
| Class | КМ(*) L4 R3-RSN oil tanker (ESP) |
| Speed | 10 knots ballast, 9 knots laden |
| Dimensions | |
| Length | 123.0 m |
| Beam | 15.3 m |
| Depth | 5.3 m |
| Draft (summer / ballast) | 3.5 m / 2.8 m |
| Cargo particulars | |
| Deadweight | 3,790 t |
| Cargo tanks | 10 x epoxy coated, total 3.558 m3 |
| Slop tank | 1, 139 m3 |
| Ballast tanks | SBT, 1,800 m3 total |
| Cargo pumps (simultaneously) | 2 x centrifugal, 180 m3/h each, 100 m head |
| Ballast pumps | 2 x centrifugal, 120 m3/h each, 60 m head |
| Loading rate (homogenous cargo) | 2 x 400 m3/h per manifold, |
| Cargo heating | Steam |
| Machinery | |
| Main engines | 2 x SKL 6NVDS, 640 kW each |
| Propulsion | 2 x FPP |
| Auxiliary engines | 3 x 6CH18/22, 110 kW each |
| Boilers | 1 x KSVV1000/5,1000 kg/Hour |
| Bunker tanks | Diesel Oil: 167 m3 / IFO: 40 m3 |
| Fuel consumption | 3.5 t/day |
| Accommodation | |
| Cabins | 8 x 1-berth, 2 x 2-berth, total 14 crew |
