180 ft x 60 ft 4-pm Spud barge (3 sisters) (keen sellers)
1 December 2019
4,900 dwt heavy lift barge
4 December 2019
5,140 dwt Cargo barges (2 sisters) (keen sellers)
Recent built and recently passed SS, Deck cargo barges with high deckload capacity and coamings. Immediately available. Location: Middle East Gulf. Enquire
| General | |
| Built | 2013 |
| Class | RINa, C ✠ Hull, Pontoon, |
| unrestricted navigation | |
| Next SS due | Oct. 2023 |
| Dimensions | |
| Length | 82.3 m (270 ft) |
| Beam | 21.4 m (70 ft) |
| Depth | 4.90 m (16.1 ft) |
| Draft | 3.20 m |
| GT | 2,140 |
| Deck & Cargo capacity | |
| Deadweight | 5,140 t |
| Cargo deck | 1,400 m2 (73.2 m x 19.1 m) |
| Deck load | 15 t/m2 |
| Coaming height | 4.0 m |
| Doors | Both sides @ midships |
Related products
-
Jack-up Barge, 250 ton pedestal crane
ABS. L x W x Depth (m): 43.0 x 30.0 x 4.20. Max. operating depth 50 meter. 250 ton pedestal crane. 575 dwt. ME. For Charter only. Inquire
-
17,000 ton Semi Submersible Heavy Lift / Launch Barge
Well equipped and documented. L x W x Depth x Draft (m): 124.0 x 31.5 x 6.7 x 5.3. Deadweight: 17,300+ ton. Deck area: ~3,600 m2. Max submerging depth (without add. floatation tanks) fwd: 8.0 m above deck, aft: 12.0 m above deck. For Charter only: Inquire
-
300 ft Deck Barge (2 sisters)
2007/2008, ABS class, Heavy load barge. Dwt 8,150 tons: Well maintained and well documented. WAF. Price: Inquire
