75 Pax DP-1 Fast Supply Crewboat / Utility Vessel
Mono hull, fixed props
ABS. L x b x d (m): 50.00 x 9.10 x 4.00. Draft 2.55 m. Speed: 25 knots, 200 m2 deck area, propulsion: 4 x 2,466 bhp, fixed props. FiFi: 2 x 600 m3/h, 75 pax + 10 crew. Price: Inquire
| VESSEL OVERVIEW | |
| Year Built: | 2014 |
| Classification: | American Bureau of Shipping _A1, HSC Crewboat, _AMS, _DPS-1 |
| Safety Regulation: | ABS and Flag State Requirements |
| Regs, Codes, Guidelines: | MARPOL, SOLAS, ISM, ISPS, IMDG |
| HULL PARTICULARS | |
| Length Overall: | 50.00 m |
| Breadth Moulded: | 9.10 m |
| Depth Moulded: | 4.00 m |
| Loaded Draft: | 2.55 m |
| CARGO DECK | |
| Clear Deck Area: | 200 m2 |
| Deck Cargo Capacity: | 200 mt |
| Deck Strength: | 2.5 mt / m2 |
| Deck Dimension: | 26.6 m x 7.4 m |
| Cargo Railing Height: | 1.0 m |
| Deck Crane | Credence, CRE230BSM 1.8 Ton @ 6 m |
| Remarks: Adequate cargo retainers and lashing lugs on both sides for securing deck cargo | |
| TONNAGE | |
| GT/NT | 470 / 140 |
| DWT: | 346 MT |
| MAIN MACHINERY | |
| Number of Main Engines: | 4 units with resilient mountings |
| Make and Type: | MTU 16 V4000 M53E IMO Tier 2, 4 x 2,466 bhp each |
| Total BHP: | @ 1800 rpm |
| Propellers: | 4 x fixed pitch, Ni-Al-Bronze, 5 blades |
| Bow Thruster: | 2 units electro-hydraulic @ 200 HP |
| Dynamic Positioning System | Kongsberg DP1 |
| PERFORMANCE | |
| Maximum Speed: | 25 knots @ 100% MCR & 150 MT DWT |
| Maximum Fuel Consumption: | 1,740 lt/hr |
| Economical Speed: | 23 knots @ 85% MCR & 150 MT DWT |
| Economical Fuel Consumption: | 1,500 lt/hr |
| Digital Fuel Consumption Monitor | Fitted |
| GENERATING SETS (AUXILIARIES) | |
| Prime Movers: | 3 x 355 BHP @ 1500 rpm |
| Make / Type: | 3 x Cummins QSM11 – DM |
| Fuel Flow Meters: | Installed on all generators |
| Generators: | 3 x Newage Stamford HCM534C |
| Vessel Power Supply: | 415/220 Volt AC, 50 Hz, 3-phase + 24 Volt DC |
| Shore Connection / Food Container Socket: 1 / 4 | |
| SEATING AND ACCOMMODATION | |
| Passenger Capacity: | Business Class 75 pax |
| VIP Room (2 men): | Fitted (Option for Sick Bay) |
| Passenger Toilets: | 2 cubicles for passenger use |
| Entertainment System: | 3 x LCD TV screens |
| Crew Cabins / Bunks: | 8 /14 |
| Crew Toilets: | 2 cubicles with shower |
| Crew Mess and Galley: | Fitted |
| Crew Washer and Dryer: | Fitted |
| Walk-In Freezer and Chiller: | Fitted |
| Dry Store (on crew deck): | Fitted |
| Public Address System: | Fitted |
| ELECTRONICS AND CONTROLS | |
| GMDSS: | Sea Area A1+A2+A3 |
| VHF: | Furuno FM-8800S, FS-1570, Furuno FM 3000 |
| SSB Radio (Non-GMDSS): | Furuno FS-1503 |
| Satellite Telephone / Email: | Sailor FB250 |
| Marine Radar: | Furuno FAR-2117 96NM |
| DGPS: | Furuno GP-150 |
| Depth / Echo Sounder: | Furuno FE-700 |
| Gyro Compass: | Anschutz, STC22 |
| Magnetic Compass: | Riviera 6″ |
| Navtex: | Furuno NX-700 |
| Public Address / Intercom System: | Vingtor Zenitel |
| Search Lights: | Kescom x 3,1000W |
| EPIRB: | McMurdo E5 |
| SART: | McMurdo S4 |
| AIS: | Furuno FA-1502 |
| Remote CCTV: | 2 x around wheelhouse |
| TANK CAPACITIES | |
| Fuel Oil: | 171.0 m3 |
| Fresh Water: | 52.0 m3 |
| Dirty Oil Tank: | 1.5 m3 |
| Dispersant: | 0.2 m3 |
| Sewage Treatment Plant: | Fitted for 20 pax |
| Oily Water Separator: | 15 ppm |
| LIFE SAVING EQUIPMENT | |
| Life Rafts: | 4 x 25 on each side |
| Life Jackets: | 109 on board |
| Life Buoys: | 8 on board |
| Scrambling Nets: | 2 units |
| Other Equipment: | Pyrotechnics, line-throwing apparatus |
| Rescue Zone: | Port and Starboard |
| EMERGENCY RESPONSE FEATURES | |
| Two external fire-fighting monitors with remote clutch @ 2 x 600m3 per hour | |
| Motorised Workboat Fitted | |
| Dispersant With Spray Boom Optional | |
