2209 Multi purpose vessel
Versatile workboat, Dredging support, Diving support, Cable repair, Supply, Anchor handling
2011, Netherlands built , BV Coastal. l x w x d (m): 22.6 x 9.0 x 2.1, Propulsion 2 x 390 kW, Bollard pull 18 tons. Knuckle boom crane 26 tons @ 5.6 m (140 tm), deck winch 50 ton pull. Accommodation for 5 crew, location: North Sea. More details: Enquire
| General | |
| Built | 2011 |
| Class | BV, I ✠ Hull, • Mach, Special Service, |
| Multi-purpose vessel, coastal area | |
| Dimensions | |
| Length | 21.6 m |
| Beam | 9.0 m |
| Depth | 3.0 m |
| Draft | 1.8 m / 2.4 m |
| GRT | 135 |
| Performance | |
| Speed | 10 knots |
| Bollard pull | 18 t |
| Deck strength | 6.0 t/m2 |
| Deck area | ± 100 m2 |
| Machinery | |
| Main engines | 2 x Cummins QSK19-M, 390 kW each |
| Propulsion | 2 x FPP in nozzles |
| Cooling | Keel cooled |
| Generators | 2 x Caterpillar, 85 kW each |
| Deck equipment | |
| Crane | Heila HLRM 140, max reach 12 m |
| AH / Towing winch | 50 t |
| Tugger winch | 10 t |
| Towing hook, push bow, bow roller, bridge winch controls, | |
| fuel & freshwater transfer, anchor handling equipment | |
| Tank capacity | |
| Fuel | 56 m3 |
| Fresh water | 28 m3 |
| Navigation & communication | |
| Magnetic Compass, GPS Compass, Daylight viewing radar, | |
| Speed log, Echo sounder, Electronic chart plotter, Watch | |
| keeping alarm, AIS, DGPS, Navtex, Talk back unit, DSC VHF | |
| Accommodation | |
| Cabins | 3 for 5 crew |
