32 tbp twin screw Tug
1982, Versatile, solid built towing tug with azimuth bow thruster, 2 x Cat 399, 895 kW each. FiFi pump and monitors as well as light salvage equipment. Location: North Sea. Enquire
| General | |
| Built | 1982, Netherlands |
| Class | RINa, C ✠ Tug MN unrestricted navigation |
| Dimensions | |
| Length | 28.5 m |
| Beam | 8.8 m |
| Depth | 4.25 m |
| Draft max | 3.8 m |
| GRT | 245 |
| Tank capacities | |
| Fuel | 95 m3 |
| Fresh water | 35 m3 |
| Foam | 6 m3 |
| Water ballast | 35 m3 |
| Performance | |
| Bollard pull | 32 t |
| Speed | 12 knots |
| Machinery | |
| Main engines | 2 x Caterpillar D399 PCTA, 895 kW each |
| Reduction gear | 2 x Reintjes WAV 1050 |
| Aux engines | 2 x Caterpillar 3304, 82 kW each |
| Generators | 2 x 95 kVA – 380/220 V at 50 Hz |
| Bow thruster | 4 tons retractable -360 degrees |
| Towing & Salvage equipment | |
| Towing winch | Hydrakraft 88-20t, split drum |
| Wires | Main: 750 m, spare: 350 m |
| Capstan aft | Steen, capacity 30-75 kn |
| MOB boat | Akva |
| Deck crane | knuckle boom PK 17500, 1 ton x 8.0 m |
| Portable pumps with various capacities | |
| Oxy-acetylene burning torch, cutting and welding | |
| Sundry steel wires, shackles, pendant and polypropylene lines | |
| Fire fighting | |
| Pump engine | 1 x Caterpillar 3306 PC-TA, 148 kW |
| Pump | 1 x 288 m3/hr Nijhuis, 10.5 bar head |
| Monitor | 2 x |
| Navigation & Communication equipment | |
| Autopilot | Anschutz Digital Pilotstar “D” |
| SSB radio | Furuno SSB FS-1562/15 |
| VHF DSC | Furuno FM-8500 |
| ch. 70 duty | Sailor RT 144c |
| Weather fax | Furuno Fax-208A MK2 |
| Navtex | Furuno OP08-2 |
| Electronic chart | Maxsea |
| GPS, DGPS | Furuno GP-80 |
| Echo Sounder | Radio Holland El 4242 |
