51 tbp Shallow draft AHT
2011, BV class, 51 tbp shallow draft AHT, Double drum, waterfall configured and accessoiries. L x B x D x draft(m): 31.0 x 10.0 x 3.45 x 2.5 . Propulsion: 2 x 1,425 kW + bow thruster. 200 tonmeter knuckle boom crane. Prompt available. present location Med. Enquire
| GENERAL | |
| Built | 2011 |
| Class | BV, I ✠ Hull • Mach, Tug, Unrestricted navigation, |
| • AUT UMS (SS) , Ice Class IB | |
| DIMENSIONS | |
| Length | 31.0 m |
| Beam | 10.0 m |
| Draft | 3.45 m |
| Operational draft | 2.5 m |
| GRT | 305 |
| MACHINERY | |
| Main engines | 2 x Cat., 1425 kW each |
| Propulsion | 2 x FPP 4-blade ø2200 mm |
| Generator | 1 x 156 kVA, 1 x 148 kVA |
| Bow thruster | 360 kW, 360 degrees |
| Power pack | Diesel driven hydraulic |
| PERFORMANCE | |
| Bollard Pull | 51 ton |
| Free running speed | 11 knots |
| DECK EQUIPMENT | |
| AH / Towing winch | 1 x 90 ton pull, 125 ton hold, 450 m ø48 mm |
| Towing winch | 1 x 50 ton pull, 125 ton hold, 1000 m ø48 mm |
| Tugger winch | 1 x 15 ton pull |
| Towing pins | 3 pins Hydraulic |
| Crane | Heila 200/20 – 200 tm with winch 10 ton single line |
| TANK / TRANSFER CAPACITIES | |
| Fuel | 146 m3 |
| Water | 32 m3 |
| Sewage | 9.0 m3 |
| ACCOMMODATION | |
| Cabins | 2 x 2-berth, 3 x 1-berth |
| Mess room/galley, sanitary, central heated, air conditioning | |
