64 tbp multi-purpose tug
2011, 64 tbp, RINa class, solid design, 2 x Cat 1750 kW each, split drum and AH accessoiries for light AH activities, location: Med. Enquire
| General | |
| Building years | 2011 |
| Classification | RINa, C ✠ HULL • MACH, ✠ AUT-UMS |
| Dimensions | |
| Length | 35.0 m |
| Beam | 9.0 m |
| Depth | 4.40 m |
| Draft aft | 4.25 m |
| GRT | 355 |
| Deck capability | |
| Free deck | 13.0 m x 6.30 m |
| Deck cargo | 85 tons – 3 t/m2 |
| Dead weight | 186 tons |
| Tank capacity | |
| Fuel oil | 193 m3 |
| Fresh water | 25 m3 |
| FW maker | 7 m3/day |
| Performance | |
| Bollard pull | 63.5 tons |
| Speed | 12.4 knots |
| Speed (economic) | 9 knots |
| range eco. Speed | 6.000 |
| Eco fuel consumption | 5 t/day |
| Machinery | |
| Main engines | 2 x Caterpillar C280-6/CS, 1750 kW each |
| Propulsion | 2 x fixed pitch propellers in nozzles |
| Bow thruster | 1 x 215 kW |
| Generator sets | 3 x Caterpillar C6.6 Acert, 143 kW each |
| Deck equipment | |
| AH / Towing winch | Split drum, brake : 1 x 150 tons + 1 x 100 tons |
| AH / Towing wires | 1 x 450 m Ø 48 mm + 1 x 850 m Ø 48 mm |
| Spare wire | 1 x 750 m Ø 48 mm |
| Towing Hook | 70 tons |
| Cam fork | 1 x combined with 2 towing pins |
| Stern roller | 35 t – 3 m width |
| Hydraulic crane | 2.2 t at 8.60 m – 1.25 tons at 12.60 m |
| Rescue boat | Fitted |
| Communication equipment | |
| Inmmarsat | Felcom 15 |
| Radio VHF | Sailor RT 5022 + VHF portable Jotron TR 20 |
| Radio MF | Furuno FS 1570 |
| Navtex | Furuno NX 700 |
| GPS | Furuno GP 150 |
| AIS | Furuno F.A. 150 |
| Radar transponder | Jotron Sart 20 |
| Echo sounder | Furuno FE 700 |
| Accommodation | |
| Cabins | 5 x 1-berth + 2 x 2-berth |
