26 x 10 Multicat
Late nineties, well maintained. BV class, 26 x 10 multicat. Propulsion 2 x 595 kW, Bow thruster. Towing/AH winch 2 x 45 t. 140 tm deck crane. Accommodation: 5 crew. Enquire
| General | |
| Built | 1998 / 1999 |
| Class | BV, I ✠ Hull • Mach, Special service/ |
| Work boat, Unrestricted navigation | |
| Dimensions | |
| Length oa | 26.0 m |
| Beam | 9.5 m |
| Depth | 2.8 m |
| Draft | 2.0 m |
| GRT | 175 |
| Performance | |
| Speed | 12 knots |
| Bollard pull | 21 ton |
| Machinery | |
| Main engines | 2 x Cummins, 595 kW |
| Propulsion | 2 x 4-blade FPP ø1380 mm |
| Bow thruster | 265 kW |
| Generator | 1 x 250 kVA and 1 x 100 kVA |
| Deck equipment | |
| Towing/AH winch | 2 x 45 ton pull (1 x constant tension), 60 ton hold |
| Towing pins | WKH 1500 |
| Auxiliary winches | 2 x 10 ton, wheelhouse operated |
| Hydraulic crane | 140 tonmeter |
| Tank – Transfer capacity | |
| Fuel | 80 m3 – 50 m3/hr at 2 bar |
| Water | 45 m3 – 40 m3/hr at 2 bar |
| Sewage | 0,6 m3 |
| Accommodation | |
| Cabins | 3 x 1-berth and 1 x 2-berth |
| Other | Mess room, galley, sanitary, air conditioning |
