34 x 13 DP-2 FiFi-1 4-PM Multicat (2 sisters)
Versatile workboat, Dredging support, Diving support, Cable repair, Supply, Anchor handling
2015, BV. DP-2, l x b (m): 34 x 13. Propulsion 2 x Cat 3512, bollard pull 40 tons. 2 x Knuckle boom crane, AH/Towing winch 125/50t pull , 190/60t hold, bow & stern roller. Accommodation for 19 crew. Location 1 x North Sea / 1 x WAF Inquire
| GENERAL | |
| Built | 2015 |
| Class | BV, I + Hull • Mach, Fire fighting ship 1 -water spraying- |
| Special service /Multi purpose ship Unrestricted Navigation, | |
| • AUT-UMS (SS) , • Dynapos AM/AT R • Mach | |
| DIMENSIONS | |
| Length o.a | 34.0 m |
| Beam o.a. | 13.0 m |
| Draft max. | 3.0 m |
| Depth moulded | 4,10 / 4,70 m |
| GRT | 498 |
| PERFORMANCE | |
| Cruising Speed | 10 knots |
| Bollard pull | 40 t approx. |
| Deck load | 8,5 t/m2 |
| Max. Deck load | 260 t |
| Free deck space | 235 m2 |
| TANK CAPACITIES | |
| Fuel | 220 m3 |
| Fresh water | 87 m3 |
| Dirty oil tank | 3,5 m3 |
| MACHINERY / PROPULSION | |
| Main engine | 2 x Cat. 3512, 1140 kw each |
| Propulsion | 2 x ASD |
| Bow thruster | 2 x Shallow draught thrusters (L-drive) – type ZF SDT 4010 |
| Generator | 2 x Cat. C18, 350 kVA each |
| Harbour generator | 1 x Cat. C6, 150 kVA |
| Air compressor | 5.0 m3/h – 10 bar |
| DECK MACHINERY | |
| Crane fwd | Heila HLRM 340-2s (340 tm) max reach 14.0 m, 15 ton winch |
| Crane aft | Heila HLRM 230-4s (230 tm) max reach, 16,5 m, 8 ton winch |
| Anchor handling winch | 125 t |
| Towing winch | 50 t |
| Tugger winch | 2 x 15 t |
| Bow / Stern roller | Fitted |
| Mooring winch | 2 x 7 t, suitable for 4 point mooring |
| Anchor handling pins | Shark jaw h-200 swl 200 t / max. 3’’ chain |
| Moonpool | Ø 600 mm ready for USBL multibeam |
| Boat landing | Removable |
| Fire fighting | FiFi-1 certified, 2 x 1,200 m3/h |
| Spuds | 2 x spuds (optional) |
| CONTROL AND NAVIGATION | |
| Autopilot | Integrated DP |
| DP system | Sirehna easy DP v3 |
| Radar | Furuno FAR-2117 |
| GPS | Furuno GP-150D |
| Wind sensor | x 2 |
| Gyrocompass | x 3 |
| Sounder | Furuno FE-700 |
| COMMUNICATION | |
| GMDSS | A3 Station |
| VSAT | Sailor 900 VSAT |
| FBB | Sailor 250 |
| ACCOMODATION | |
| Cabins | 3 x 1-berth, 8 x 2-berth |
| Total | 19 |
