42 x 12 DP-2 Multi-purpose Utility Vessel
Versatile workboat, Dredging support, Diving support, Cable repair, Supply, Anchor handling
2019 rebuilt, BV. DP-2, l x b (m): 42 x 12. Propulsion 2 x Cat 3512, bollard pull 40 tons. 2 x Knuckle boom crane, 125/50t pull , 190/60t hold Towing AH winch, bow & stern roller. Accommodation for 23 persons. Inquire
| General | |
| Built / rebuilt | 2014 / 2019 |
| Class | BV, I ✠ Hull • Mach, Special service / |
| Multi purpose ship, • AUT-UMS (SS), | |
| l Dynapos AM/AT R | |
| Dimensions | |
| Length | 42.0 m |
| Beam | 12.0 m |
| Depth | 3.7 m |
| Draft | 2.9 m |
| GT | 498 |
| Performance | |
| Speed max | 10 knots, 10 m3/day |
| eco | 7 knots, 5 m3/day |
| Bollard pull | 40 ton |
| Deck area | 280 m2 |
| Dynamic positioning | DP-2 |
| Machinery | |
| Main engines | 2 x Cat 3512, 1140 kW each |
| Propulsion | 2 x Azimuth thruster (flush with keel) |
| Bow thruster | 2 x 250 kW, Azimuth (flush with keel) |
| Generators | 2 x Cat. C18, 383 kW each |
| Port generator | 1 x Cat. C6.6, 108 kW |
| Deck equipment | |
| AH / Towing winch | 1 x 125 t pull, 190 t hold |
| 1 x 50 t pull, 60 t hold | |
| Shark jaws Fwd | Hydraulic, triple set |
| Towing pins | Hydraulic, 1 set |
| Crane # 1 | 45 t @ 3.0 m, max reach 14 m |
| Crane #1 winch | 15 t, 30 m wire |
| Ceane #2 | 32 t @ 2.5 m, max reach 16.5 m |
| Push bow | Forward & aft |
| Stern roller | Yes |
| Bow roller | Yes |
| Rescue boat | Yes |
| Optional | Boat landing |
| 2 x spuds | |
| AHC walk 2 work | |
| Tank capacities | |
| Fuel | 195 m3 |
| Freshwater | 80 m3 |
| Sewage | 12 m3 |
| Communication | |
| As per flagstate, class and operational requirements | |
| VSAT – broadband | Yes |
| Intranet | Yes |
| Accommodation | |
| Cabins | 9 x 2-berth, 5 x 1-berth, total 23 |
| Other | Client (survey) office, meeting room, |
| Changing room, mess room, galley, | |
| Sanitary, laundry, freezer room, | |
| cold room, Central heated, AC | |
