38 tbp 3200 bhp 36m Tug
Coastal Towage, Barge Handling, General assistance
2008, BV, l x w x d (m): 36.10 x 10.60 x 4.90, Draft 4.0m. 2 x Cummins KTA50, 1,600 bhp each, Far East. Inquire
| GENERAL | |
| Built | 2008 |
| Class | B.V., 1 + Hull + Mach Tug, Unrestricted Navigation |
| DIMENSIONS | |
| Length Overall | 36.10 m |
| Breadth Moulded | 10.60 m |
| Depth Moulded | 4.90 m |
| Draught Designed | 4.00 m |
| GRT | 473 |
| PERFORMANCE | |
| Maximum Speed | 12.0 knots |
| Type of Fuel | Marine Gas Oil |
| Bollard Pull | 38.5 t (Static) |
| CAPACITIES | |
| Fuel Oil | 390 m³ |
| Fresh Water | 70 m³ |
| Ballast Water | 59.8 m³ |
| Dirty Oil | 9.2 m³ |
| DISCHARGE RATES | |
| Fuel Oil | 1 x 25 m³/hr @ 0.6 Mpa |
| Fresh Water | 1 x 21 m³/hr @ 21m Head |
| MACHINERY | |
| Main Engines | 2 x Cummins KTA50-M2, 1600 bhp each |
| Gear Box | TwinDisc MG5506 (Ratio 6:1) |
| Diesel Gen. Set | 2 x Cummins 6CT.8.3GM115, 100 kW each |
| Bow Thruster | HRP 2001 TT (2.8T Thrust) |
| Bow Thruster Engine | Cummins NT855-M270, 202 kW |
| Propellers | FPP x 2 (with Kort Nozzle) |
| Rudders | 2 x Conventional |
| ACCOMMODATION | |
| Cabins | 2 x 1 man cabin = 2 men |
| 2 x 2 men cabin = 4 men | |
| 2 x 4 men cabin = 8 men | |
| Total | 14 berth |
| All cabins fully air-conditioned | |
| DECK | |
| Deck Strength | 5 tonnes/m2 |
| Clear Deck Area | 160 m2 |
| RADIO & NAVIGATION EQUIPMENT | |
| Radar no.1 | 1 x Furuno (FR-1510 MK3) |
| Radar no.2 | 1 x Furuno (FR-1942 MK2) |
| Magnetic Compass | 1 x Furuno |
| GPS | 1 x Furuno (GP-150) |
| Anemometer | 1 x Navman (W3150) |
| Echo Sounder | 1 x Furuno (FE-700) |
| Speed Log | 1 x Furuno (DS-80) |
| Gyro Compass | 1 x Anschütz (Standard 22) |
| AIS | 1 x Furuno (FA-150) |
| Autopilot | 1 x Anschütz (NP60) |
| GMDSS Radio | 2 x Furuno (FM-8800S/DSC) |
| EPIRB | 1 x McMurdo (E3) |
| SART | 2 x McMurdo (S4) |
| Navtex | 1 x Furuno (NX-700B) |
| Weather Fax | 1 x Furuno (FAX-408) |
| DECK & AUX. EQUIPMENT | |
| Anchor Windlass | Elec. Hydr., 3.5 Tonnes @ 10m/min |
| Bow Anchor | Stockless, 2 x 660kg |
| Anchor Chain/Cable | 302.5m length @ 26mm Dia. Grade 2 Stud link chains |
| Towing Winch | Elec. Hydr., 40 Tonnes @ 5m/min |
| Break Holding | 100 Tonnes |
| Drum Capacity | 900m / 44mm Dia. Wire rope |
| Towing Hook | 50 Tonnes SWL c/w quick release control |
| FIRE FIGHTING EQUIPMENT | |
| Fire Main | 1 x 36 m3/hr @ 41m Head |
| Other internal | As per SOLAS and Class requirements |
| Emer. Fire Pump | 25 m3/hr @ 40m Head, Engine Driven |
| Fixed CO2 System | Engine Room |
| LIFE SAVING EQUIPMENT | |
| Inflatable Liferaft | 2 units x 15 person |
| All other | As per SOLAS and Class requirements |
| OTHERS | |
| Sewage Plant | 1 unit (cap: 1 Tonnes) |
| Separator | 1 unit (cap: 0.5 m3/hr) @ 15 ppm |
