14 tbp Coastal Tug
Coastal Towing, Barge Handling, General Support
1993 (2014 refit), BV. l x w x d (m): 21.00 x 6,00 x 3,30, 2 x Cummins KTA-19, 404 kW each. Location: North Sea. Inquire
| GENERAL | |
| Built (refit) | 1993 (2014) |
| Class | BV, I Hull • MACH • AUT-UMS, |
| Tug, Coastal Area | |
| DIMENSIONS | |
| Length | 21,00 m |
| Width | 7,00 m |
| Depth | 3,30 m |
| Draft max. | 3,40 m |
| GT / NT | 122 / 37 |
| TANK CAPACITIES | |
| Fuel oil / gasoil | 69,0 m3 |
| Fresh water | 18,0 m3 |
| Lube oil | 3,9 m3 |
| PERFORMANCE | |
| Speed free sailing (ave.) | 8.4 knots |
| Endurance with / without tow | 2.500 / 4.000 naut. miles |
| Bollard pull | 14 tons |
| MACHINERY | |
| Main engines | 2 x Cummins KTA-19-M, 404 kW each |
| Generators | 2 x Perkins RE51275, 47 kVA each |
| DECK EQUIPMENT | |
| Towing winch | Single drum |
| Tow wires | 1 x 650 m x 28 mm |
| Towing hook | 1x Mampay 45 ton SWL |
| NAVIGATION & COMMUNICATION | |
| Radar, echosounder, speed log, GPS, autopilot, compass, | |
| AIS, Navtex, Sart, Epirb, VHF, SSB | |
