15 tbp shallow draft AHT
Towing, AHT, Dredge Support
2013, BV. l x w x d (m): 23.00 x 8,00 x 3,10. Max Draft: 2,60 m , 2 x Cat. C18, Winch, Double drum, Waterfall configuration. Inquire
| GENERAL | |
| Year of built | 2012 |
| Classification | Bureau Veritas, I HULL MACH AUT – |
| UMS unrestricted | |
| DIMENSIONS | |
| Length over all | 23,00 m |
| Width | 8,00 m |
| Depth midships | 3,10 m |
| Draft max. | 2,60 m |
| GT / NT | 135 / 40 |
| CARGO / TANK CAPACITIES | |
| Deck cargo cap. | 2 TEU – 30 tons |
| Clear deck area | 35,0 m2 |
| Cargo deck load | 3,0 t/m2 |
| Fuel oil / gasoil | 40,0 m3 |
| Fresh water | 20,0 m3 |
| PERFORMANCE | |
| Speed free sailing (ave.) | 10,0 knots |
| Endurance with/without tow | 2.500 / 3.600 naut. miles |
| Bollard pull | 15 tons |
| MACHINERY | |
| Propulsion | 2 x Cat. C18, 358 kW each |
| Generators | 2 x Cat. C 4.4. DI, 45 Kva each |
| Bow thruster | 92 kW |
| DECK EQUIPMENT | |
| Towing winch | Doubledrum waterfall |
| Tow wires | 1 x 450 m and 1 x 75 m |
| Tow wire diameter | Mainwire 30 mm |
| Knuckle Boom crane | Heila 25/3S – 25 tonmeter |
| 8.0 tons @ 2.80 m | |
| 2.0 tons @ 10.50 m | |
| NAVIGATION & COMMUNICATION | |
| Sea/river radar, GSM, 2 x echosounder, speed log, GPS, autopilot, 2 x compass, AIS, Navtex, Sart, Epirb, 3 x VHF, SSB, 2 x Inmarsat C, Satcom-C | |
