32 x 11 Multi-purpose Utility Vessel
Versatile workboat, Dredging support, Diving support, Cable repair, Supply, Anchor handling, 4-point mooring
2012, BV class. l x w x d (m): 32.00 x 11.00 x 2.85, M/E: 2 x Cummins 1.400 hp each, bollard pull 36 tons. 2 x Knuckle boom crane, AH/Towing winch, bow & stern roller. Accommodation for 11 crew. Location: South China Sea. For charter only: Inquire
| General | |
| Built | 2012 |
| Classification | Bureau Veritas 1+ Hull – Machinery, Special Service, Multi Purpose Ship, Unrestricted Navigation. |
| Dimensions | |
| Length | 32.0 m |
| Beam | 11.0 m |
| Draft | 2.8 m |
| Performance | |
| Bollard pull | 36 tonnes |
| Speed | 10 knots max |
| Machinery | |
| Main Engines | 2 x Cummins QSM38, total 2,800 bhp |
| Propulsion | FPP in nozzles, Twin Disc MG5321 reverse reduction gearboxes |
| Generators | 2 x Caterpillar C9 + 1 x Caterpillar C6 |
| Bow thruster | 265 bhp |
| Supply pumps | Fuel and Fresh water and hoses |
| Tank Capacities | |
| Fuel | 153 m³ |
| Fresh Water | 49 m³ |
| Dirty Water | 10.5 m³ |
| Equipment | |
| Winch #1 | 80 tonne |
| Winch #2 | 50 tonne |
| Tugger winch | 15 tonne |
| Anchoring | 4 point mooring system, 4×7 tonne hydraulic winches |
| Crane aft | 230 tm knuckle boom crane Heila HLRM 200-4SL mx reach 16.3 m |
| Crane forward | 140 tm knuckle boom Heila HLRM 140-3S Crane |
| Towing hook, push bows, bow roller, hardwood covered working deck, anchor handling gear includes sharks jaws and hydraulic pin arrangement forward plus hydraulic pins aft, stern roller, container points on deck, container locking points | |
| Navigation | |
| Aids Magnetic and GPS compasses, autopilot, 2 x daylight viewing radars, speed log, echosounder, Inmarsat C9, 2 x DSC VHF radios, MF/HF radio, electronic chart display, watch keeping alarm, AIS, DGPS navigator, Navtex, talkback units, searchlight, GSM phone, iridium Satphone with email | |
| Accommodation | |
| 11 heated and air conditioned cabins, 5 of which are twin berth | |
