25 x 11 Multi-purpose Utility Vessel
Versatile, Anchor handling, Dredging support, Diving support, Cable repair, Supply.
2008, Spain, GL unrestricted. l x w x d (m): 25.0 x 11.6 x 3.5, Draft 2.5 m. Propulsion 3 x 612 kW, 3 x fixed props, bowthruster 100 kW, Bollard pull 30 tons. 2 knuckle boom cranes 10 tons @ 14 m & 6,5 ton @ 12,5 m with hoisting winches, deck winch 50 ton line pull. Stern roller & bow roller and many other AH features. Accommodation for 6 crew, location: SE Asia. Price: Inquire
| GENERAL | |
| Year Built | 2008 |
| Class | GL, ✠ 100 A5 Tug RSA(50), MC |
| PERFORMANCE | |
| Speed max | 11.5 knots |
| Speed eco | 8 knots |
| Bollard Pull | 30 t |
| DIMENSIONS | |
| Length oa | 25.0 m |
| Beam | 11.6 m |
| Depth | 3.50 m |
| Draft | 2.50 m |
| GRT | 250 |
| DECK EQUIPMENT | |
| Deck Crane 1 | Heila, 10 t at 14 m |
| Deck Crane 2 | Heila, 6.4 t at 12.6 m |
| Towing Winch | 500 m x 35 mm, 30 t pull |
| Anchor Handling Winch | 100 m x 50 mm, 80 t pull |
| Capstan | 2 x 15 t |
| Tugger Winch | 15 t Hydraulic |
| Shark Jaws | 3” Chain Max |
| Bow Roller | 160 t, 5.4 m x 1.2 m |
| Stern Roller | 60 t, 1.5 m x 0.7 m |
| Spud Fittings | 2 x 550 mm |
| *Pre-installation for 4 point mooring | |
| *Deck floor fully covered with interchangeable wooden inserts | |
| MACHINERY | |
| Main Engines | 3 x Vector 750 / 612 kW each |
| Propulsion | 3 x FPP |
| Bow thruster | 185 kW, 360º |
| Hydr. power packs | 1 x 390 kW + 1 x 52 kW |
| Generators | 2 x Iveco, 100 kW each |
| Port Generator | 1 x Iveco 20 kVa |
| TANK / PUMP CAPACITIES | |
| Fuel Oil | 121 m³, 1 x 60 m³/h |
| Fresh Water | 68 m³, 1 x 60 m³/h |
| Ballast Water | 80 m³ |
| NAVIGATION EQUIPMENT | |
| 2 x Radar | 2 x Furuno |
| Compass | Furuno |
| Echo Sounder | Furuno FE-700 |
| DGPS | Furuno-37 |
| DGPS | Furuno-90 |
| Autopilot | Robertson AP-50 |
| Navtex | Furuno NX-700A |
| VHF Radio | 2 x Sailor RT-5022, DSC |
| GMDSS Portable VHF | 2 x Sailor SO-3520 |
| Chart Plotter | Furuno Nav Net |
| Inmarsat Mini C GMDSS | TT-3000E, A1/A2 |
| Navigation Software | Navigator Plus. MEXSEA |
| Anemometer | Walker, speed and direction |
| AIS | Transmitter & Reciever |
| ACCOMMODATION | |
| Cabins | 3 x 2-berth |
| Galley, sanitary facilities, air conditioning (heat & cold) | |
| MISCELLANEOUS | |
| Moonpool | Ø 1,000 mm |
| Deck container fittings for 20’ container | |
