57 tbp Escort (FiFi-1) ASD Tug (multiple sisters)
BB charter only: Well maintained 2008/2010, Damen 2810, 57 tbp, 2 x Cat 3516, 1,774 kW each, 2 sisters equipped with FiFi-1. Escort winch: Split drum, Towing winch: Single drum, Accommodation: 5 cabins for 8 crew. Loaction: Caribbean. Enquire
| General | |
| Built | 2005-2010 |
| Class | LR, ✠ 100 A1 Tug, (Fire Fighting Ship 1), |
| [✠] ALMC UMS | |
| Dimensions | |
| Length | 28.6 m |
| Beam | 10.4 m |
| Depth | 4.60 m |
| Draft | 4.9 m |
| GRT | 295 |
| Performance | |
| Speed | 13.6 knots ahead, 13.7 knots astern |
| Bollard pull | 57.3 t ahead, 56 t astern |
| Propulsion system | |
| Main engines | 2 x Caterpillar 3516B TA HD/C, 1774 kW each |
| Azimuth thrusters | Rolls Royce US 205 MK 2 |
| Generator sets | 2 x Caterpillar C4.4 TA, 230/400 V, 107 kVA, 50 Hz |
| Hydr. power packs | 2 x M/E driven pumps |
| FiFi pump set | Caterpillar 3406C T, 600 m³/h |
| FiFi monitors | 1 x 600 m³/h, water/foam |
| Deck equipment | |
| Escort winch | Split drum, hydr. 150 ton brake |
| 30 t pull 11 m/min up to 33 m/min | |
| Towing winch | Single drum, hydr. 150 ton brake |
| 30 ton pull at 11 m/min, up to 33 m/min | |
| Capstan | electric, 5 ton at 15m/min |
| Towing hook aft | Mampaey 65 ton |
| Fendering | All around bow and stern |
| Searchlight | 2x Pesch 1000 W |
| Tank capacities | |
| Fuel oil | 100 m3 |
| Fresh water | 15 m3 |
| Foam | 8.0 m3 |
| Dispersant | 4.5 m3 |
| Navigation and communication equipment | |
| GMDSS | A3 |
| Radar | Furuno FR-1505 |
| Satellite compass | Furuno SC-50 |
| Autopilot | Simrad AP-50 |
| GPS | Furuno GP-150 |
| Echosounder | Furuno FE-700 |
| VHF | 2x Sailor RT-5022 with DSC |
| Navtex | Furuno NX-700 |
| SSB | Furuno FS-1570 |
| AIS | Furuno FA-150 |
| Inmarsat C | 2x Furuno Felcom 15 |
| Inmarsat Mini M | sailor tt-3064a |
| Weatherfax | Furuno fax408 |
| Accommodation | |
| Cabins | 5 for 8 persons |
| Other | Galley, mess/dayroom, dry store and sanitary facilities |
| Air-conditioned and heated accommodation | |
