70 tbp ASD Tug NB (2 sisters)
Coastal Towage, Terminal, Harbour, FiFi-1
RAmparts 2500W, ASD, 70tbp, Class: RINa, solidly built & versatile, Dimensions (m): 25,60 x 12,00 x 4,60. Delivery Turkey October / November 2016. Price: Inquire
| GENERAL | |
| Type | ASD |
| Model | RAmpart 2500 W |
| Class | RINa |
| Notation | I + HULL + Machinery, Tug, Unrestricted Navigation – AUT-UMS FiFi-1 |
| DIMENSIONS | |
| Length overall | 25,60 m. |
| Breadth, molded | 12,00 m. |
| Depth, molded | 4,60 m. |
| Loaded Draught | 5,10 m. |
| GT | 348 (approx.) |
| PERFORMANCE | |
| Bollard pull | 70 Tons – ahead at %100 MCR (approx.) |
| Speed (free running) | 12 knots (approx.) |
| ENGINES & PROPULSION | |
| Main Engines | 2 x CAT 3516C 2,100 kW at 1,600 rpm, D-rating or equal |
| Z Drive Propulsion Units | RR US255 P20 CP or equal |
| Diesel generators | 2 x Perkins genset Approx 84 KW by 1500 rpm 50 Hz |
| Voltage & Frequency | 400V-50Hz |
| TOWING EQUIPMENT | |
| Winches Fwd | 1 pc Fore Anchor towing winch, DMT type 111-E20.5K2 (300KN) or equal one chain lifter & one drum. Drum is capable of 200 meter 48 mm dia rope. |
| Winches Aft | 1 pc Electrical aft winch DMT type 011-E300 kN or Equal with one drum 600 meter 48 mm dia rope. |
| Towing hook | Mampaey Quick Release Disc Type Towing Hook |
| FIRE FIGHTING (external) | |
| FI-FI system | 1 x integrated control system, for two monitors, including clutch for 1 x FiFi pump connecting to each main engine’s PTO PLC based interlock function for engine ready to start fi-fi and valve position. |
| Main fire pump | 1 x fire-fighting pump |
| Type | Horizontal centrifugal |
| Capacity | 2 x approx 1.355 m3/h at 120 mwc |
| Water / foam monitors | 2 x remote operated monitor with remotely operated F/J nozzle. |
| CREW | |
| Complement | 6 |
| DECK EQUIPMENT | |
| Crane | Optional |
| LIFE SAVING EQUIPMENT | |
| Liferaft | 2 x 8 persons |
| Lifeboat | Hatecke or equal |
| NAVIGATION & COMMUNICATION | |
| JRC – POLAR complying GMDSS A3 area | |
