68 tbp FiFi-1 Escort ASD Tug
For Sale: 2010 built LR class, Damen 3211. Main engines: 2 x Cat 3516. Double drum escort winch, Single drum towing winch. Accommodation for 13 crew. Location: South East Asia. Enquire
| General | |
| Built | 2010 |
| Class | LRS, ✠ 100 A1 Escort Tug [✠] |
| LMC UMS Fire-Fighting Ship 1 | |
| Performance | |
| Speed | 13 knots |
| Bollard pull | 68 t ahead / 66 t astern |
| Dimensions | |
| Length | 32.0 m |
| Beam | 11.0 m |
| Depth | 5.4 m |
| Draft | 5.4 m |
| GRT | 374 |
| Machinery | |
| Main engines | 2 x Cat. 3516B TA, 2090 kW each |
| Propulsion | 2 x Aquamaster US 255 |
| Generators | 2 x Cat. C4.4 TA, 107 kVA each |
| Deck equipment | |
| Escort winch | Split drum, hold 150 t, pull 82 t @ 6 m/min |
| Towing winch | Single drum, hold 150 t, pull 60 t @ 8 m/min |
| Towing hook | 70 t, disc type |
| Fire Fighting and Oil Recovery | |
| Class | FiFi-1 |
| Pumps | 2 x 1400 m³/h, M/E driven |
| Monitors | 2 x 1,200 m³/h |
| Dispersant pump | DP20 |
| Tank capacity | |
| Fuel | 172 m³, 34 m³/h |
| Fresh water | 56 m³ |
| Foam | 15 m³ |
| Dispersant | 6.4 m³ |
| Navigation & Communication | |
| Area | A3 |
| Accommodation | |
| Cabins | 3 x 1-berth, 1 x 2-berth, 2 x 4-berth |
| Other | Mess room, galley and sanitary spaces |
| Air conditioned | |
