55 tbp FiFi AHTS
2008, BV. Loa 55.0 m, width 13.80 m, depth 5.5 m, max draft 4.3 m. Deck Area 330 m2. Location: Middle East. Inquire
| GENERAL | |
| Built: | 2008 |
| Class: | BV, I + Hull + Mach, Supply vessel /Anchor Handling |
| Vessel, Unrestricted navigation, + MACH | |
| DIMENSIONS | |
| Length: | 55.00 m |
| Breath: | 13.80 m |
| Depth / Draft: | 5.50 m / 4.30 m |
| GRT: | 1125 |
| Deck Space: | 29 m x 11.4 m = 330 m² |
| Deck Strength: | 5 tons / m² |
| PERFORMANCE | |
| Max Speed: | 12 knots |
| Bollard Pull: | 55 tons |
| MACHINERY | |
| Main Engine: | 2 x Caterpillar 3516B, 2100 bhp each |
| Main Generator: | 3 x Caterpillar 3406C, 245 kW each |
| Bow Thruster: | 5 tons – Fixed Pitch type |
| Gear Box: | 2 x Reintjes WAF 763 |
| Propulsion: | Fixed pitch Propeller |
| Emergency Genset: | 1 x 84kW |
| DECK EQUIPMENT | |
| AH / Towing Winch: | Double Drum type – 75 tons |
| Wire Rope: | Work wire: 150 m x 52 mm |
| Tow wire: 600 m x 52 mm | |
| Tugger Winch: | 2 x 5 tons |
| Stern Roller: | 1.5 m x 4.5 m, SWL 200 tons |
| Capstan: | 2 x 5 tons @ 15 m / min |
| Sharkjaw / Towpin: | 200 tons SWL |
| Crane: | 2 tons SWL @ 6 m |
| SAFETY EQUIPMENT | |
| Fire Fighting: | 2 x 600m³ / hr monitors with fire curtain |
| Engine Room: | CO2 flooding system |
| Life Raft: | 6 x 15 men self-inflatable |
| TANK CAPACITY | |
| Fuel Oil: | 428 m³ |
| Fresh Water: | 504 m³ |
| Lube Oil: | 3.4 m³ |
| Hydraulic Oil: | 11 m³ |
| Sewage Tank: | 8.4 m³ |
| Mud Tank: | 142 m³ |
| Cement Tank: | 113 m³ |
| Ballast Tank: | 180 m³ |
| ACCOMMODATION | |
| Cabin: | 2 x 1-berth, 4 x 2-berth, 5 x 4-berth |
| Total: | 30 men |
| NAVIGATION / COMMUNICATION EQUIPMENT | |
| Radar: | 2 x JRC – 48 nm / 96 nm |
| Echo Sounder: | Furuno FE 700 |
| AIS: | JRC, JHS-182 |
| GPS: | JRC, JNAV 50 |
| Auto Pilot: | JRC, Comnav |
| Gyro compass: | Yokogawa |
| Magnetic compass: | Sakura |
| Inmarsat C: | JRC, JUE – 85 |
| SSB: | JRC, JSB-196 GM |
| VHF: | JRC, JHS-32B |
| Navtex: | NCR333 |
| EPIRB: | 2 x McMurdo E3 |
| SART: | JQX-30A |
| Search Light: | 2 units – 2000W |
| PA System: | 1 unit – Fitted |
| Speed Log: | JRC |
