Multi Purpose Patrol Vessel
20 September 2016
60 tbp DP-1 FiFi-1 (2 sisters)
21 September 2016
50 tbp 40m AHTS
Ocean & Coastal Towage, Anchor Handling & Supply
2006, BV class, l x w x d (m): 40.00 x 11.80 x 4.6, 2 x Cat. 3512, 1,450 kW each, Towing/AH winch waterfall configuration. Sternroller and other AH related equipment. 2 x 600 m³/hr monitors. Inquire
| GENERAL | |
| Vessel Type | Anchor Handling Tug Supply |
| Year Built | 2007 |
| Classification | BV + Hull + Mach, Unrestricted Navigation, Tug |
| DIMENSIONS | |
| Length Overall | 40.0 m |
| Breadth | 11.8 m |
| Depth Moulded | 4.6 m |
| Maximum draft | 3.8 m |
| Clear deck Space | 150 m² |
| Deck loading | 5 t/m² |
| GT | 499 |
| PERFORMANCE | |
| Max Speed | 12 knots |
| Bollard Pull | 50.85 t |
| CAPACITY | |
| Fuel Oil | 350 m³ |
| Potable Water | 160 m³ |
| Sewage Holding Tank | 9.3 m³ |
| Foam | 7.8 m³ |
| MACHINERY | |
| Main Engines | 2 x Caterpillar 3512, 1,450 kW each |
| Generators | 2 x Caterpillar 3406C, 200 kW each 415v 50Hz |
| Bow Thruster | HRP 3001TT 220 kW |
| Propulsion | Fixed pitch in Kort Nozzles |
| ACCOMMODATION | |
| Berths | 2 x 1-berth cabin, 2 x 2-berth cabin, |
| 1 x 4-berth cabin, 2 x 4-berth cabin | |
| Total | 18 |
| FIRE FIGHTING | |
| Monitors | 2 monitors @ 600 m³/hr |
| Pumps | 1,200 m³/hr |
| DECK EQUIPMENT | |
| Towing / AH Winch | Waterfall double drums |
| Pull | 50 t |
| Brake Holding | 120 t |
| Wire Capacity | 1000 m x 48 mm |
| Tugger Winch | 2 units, 5t 1st layer, 100m x 26mm |
| Towing Pins | Hydraulic type 100 t SWL |
| Shark Jaws | Hydraulic type 100 t SWL |
| Stern Roller | 1.45 x 3.5m SWL, 150 t |
| Crane | 2 t @ 6 m |
| LIFESAVING | |
| Liferafts | 4 x 18 man |
| Lifejackets | 28 |
| Lifebuoys | 8 |
| Rescue Boat | Narwhal SV420 |
