105 tbp DP-2 FiFi-1 AHTS
2011, ABS. Loa 70.50 m, width 16.60 m, depth 7.20 m, max draft 5.90 m. DW 2,500 tons. Deck Area 480 m2. Location: Singapore region. Price: Inquire
| General | |
| Built | 2011 |
| Class | ABS, ✠ A1, Towing Vessel, AH, |
| Fire Fighting Vessel Class 1, | |
| Offshore Support Vessel, | |
| Ⓔ, ✠ AMS, ✠ DPS-2 | |
| Dimensions | |
| Length | 70.5 m |
| Beam | 16.6 m |
| Depth | 7.2 m |
| Draft (max) | 5.9 m |
| GT | 2,560 |
| Performance | |
| Speed (max) | 14.4 knots |
| Bollard Pull | 105 t (2015) |
| Deck & Cargo capabilities | |
| Deadweight | 2,500 t |
| Clear deck Space | 480 m² |
| Deck cargo | 900 tons |
| Deck loading | 10 t/m² |
| Machinery | |
| Main Engines | 2 x Niigata 8MG28, 2942 kW ea |
| Propulsion | 2 x CPP in nozzles |
| Bow thruster | 2 x 680 kW tunnel, 10.5 t ea |
| Stern thruster | 1 x 680 kW tunnel, 10.5 t |
| Shaft generator | 2 x 1,800 kW |
| Generators | 2 x Volvo D12D, 350 kW each |
| Harbour Generator | 1 x Volvo D12 |
| Water Maker | 5 m³/Day |
| Deck equipment | |
| AH / Towing winch | 280 t hold, 210 t pull waterfall |
| Wires | 2 x 1,200 m x 64 mm |
| Tugger winch | 2 x 12 t, 24 mm x 200 m |
| Cable lifters | 2 x Ø76 and Ø81 mm chains |
| Storage drum | 1,200 m x 64 mm |
| Towing pins | 2 x 300 t Karmoy |
| Shark jaws | 1 x 300 t Karmfork |
| Stern roller | 1 x 300 t, 6 m x 2 m |
| Crane | 1 x 5.9 t Palfinger Telescopic |
| FRC | 1 x 4.5 m c/w davit |
| Deck sockets | 2 x 440 V, 2 x 220 V |
| Tank & Transfer capacities | |
| Fuel | 988 m³, 1 x 100 m³/hr @ 80m head |
| Potable water | 440 m³, 1 x 100 m³/hr @ 80m head |
| Drill water | 600 m³, 1 x 100 m³/hr @ 80m head |
| Oil based mud | 497 m³, 2 x 75 m³/hr @ 80m head |
| Dispersant | 13.2 m³ |
| Dry Bulk | 220 m³, 2 x 20 m³/hr |
| Foam | 10 m³ |
| Fire Fighting / Anti-Pollution | |
| Class | FiFi-1 |
| Monitors | 2 x 1,200 m³/hr |
| Pumps | 2 x 1,700 m³/hr @ 120 m head, |
| M/E driven | |
| Spray booms | 1 set c/w 2 6 m (6 nozzles each) |
| Accommodation | |
| Cabins | 4 x 1-berth, 3 x 2-berth, 8 x 4-berth |
| Other | Mess, galley, sanitary |
