155 tbp DP-2 FiFi-1 AHTS
2009, ABS. Loa 75.40 m, width 16.80 m, depth 7.50 m, max draft 6.10 m. DW 2,190 tons. Deck Cargo 1,000 tons. Deck Area 500 m2. Location: Far East. Price: Inquire
| GENERAL | |
| Built | 2009 |
| Classification | ABS + A1, Towing Vessel, Fire Fighting Vessel Class 1, |
| Offshore Support Vessel AH, (E), + AMS, + ACCU, + DPS-2 | |
| DIMENSIONS & DETAILS | |
| Length Overall | 75.40 m |
| Breadth | 16.80 m |
| GRT / NRT | 2,950/886 |
| Deadweight | 2,190 t |
| Depth Moulded | 7.50 m |
| Maximum draft | 6.10 m |
| Clear deck Space | 500 m² |
| Deck loading | 1,000 tons (7.5 mt/m2 uniform loading) |
| Max Speed | 14.8 knts |
| Economical speed | 12.0 knts |
| Bollard Pull tonnes | 155 t |
| Rudders | 2 x 2 Becker Rudder |
| MACHINERY | |
| Main Engines | 2 x 4,500 kW Wartsila 9L32 |
| Generators | 2 x 410 kW Caterpillar 3408 DITA |
| Shaft Alternator | 2 x 2,300 kW Leroy Somer |
| Bow Thruster | 2 x 600 kW, CPP 11.2t Thrust |
| Stern Thruster | 1 x 600 kW, CPP 10.2t Thrust |
| Propulsion | 2 x CPP |
| DECK EQUIPMENT | |
| Towing Winch | |
| Type | I.P. Huse AS N6487 Haroy Norway |
| Pull Line | 300 mt @ 1st. Layer (4 pumps) (2 drive unit) |
| Brake Holding | 450 t |
| Wire Capacity | 76mm x 2,000m |
| Anchor Handling Winch | |
| Type | Brattvaag SL300W / BSL300W |
| Pull Line | 300 mt @ 1st. Layer (4 pumps) (2 drive unit) |
| Brake Holding | 450 t |
| Wire Capacity | 73mm x 2,000 m |
| Other Deck Equipment | |
| Tugger Winch | Number & Capacity 2 x 10t Hydraulic |
| Wire Capacity 22mm x 200m | |
| Storage Drum | Electro-hydraulic, 76mm x 2,000m |
| Towing Pins | 2 x 300t Karmoy |
| Shark Jaws | 2 x 300t Karmfork |
| Stern Roller | 1 x 500t 4.5m x 2.3m |
| Crane | 1 x 2.2t @ 12.2 m; 5.9t @ 6m |
| Water Maker | 10 m³/Day |
| FIRE FIGHTING | |
| Class | FiFi-1 |
| Monitors | 2 x 1,200 m³/hr |
| Pumps | 2 x 1,818m³/hr |
| TANK CAPACITY | |
| Fuel Oil | 1,263 m³ |
| Fresh Water | 430 m³ |
| Drill Water | 430 m³ |
| Oil Based Mud | 515m³ |
| Dispersant | 7.5m³ |
| Dry Bulk | 226m³ in 4 tanks |
| Foam | 7.5m³ |
| PUMPING RATES | |
| Fuel Oil | 200 m³/hr @ 90m head |
| Potable Water | 150 m³/hr @ 90m head |
| Drill Water | 200 m³/hr @ 90m head |
| Oil Based Mud | 2 X 75 m³/h @90mtrs head |
| Dry Bulk | 2 x 20 m³/hr |
| LIFE SAVING EQUIPMENT | |
| Liferafts | 6 x 25 man |
| FRC/Rescue Boat/Davit | 1 x Semi Rigid Rescue Boat Narwhal SV-480 |
| Immersion Suits | 56 |
| ACCOMMODATION | |
| Berths | 10 x 1-man cabin, |
| 8 x 2-men cabins, | |
| 4 x 6-men cabin | |
| Total | 50 |
