60 tbp AHTS, DP-1, FiFi-1 waterspray
2004, BV, Loa 48.00 m, width 13.20 m, depth 5.20 m, draft 4.20 m. Deadweight +/- 860 tons. deck cargo: +/- 300 tons. Deck area 250 m2, accommodation 24 persons. ME Gulf Region Price: Inquire
| PRINCIPAL PARTICULARS | |
| Year Built: | 2004 |
| Class: | Bureau Veritas |
| Notation: | + Hull + Machinery Supply Vessel; Fire Fighting Ship 1 Water Spraying Unrestricted Navigation |
| DIMENSIONS | |
| Length Overall: | 48.00 m |
| Length Waterline: | 45.56 m |
| Breadth Moulded: | 13.20 m |
| Depth Moulded: | 5.20 m |
| Draft Moulded: | 4.20 m |
| GRT: | 964 |
| Deadweight: | 860 t |
| PERFORMANCE | |
| Maximum speed: | 12 knots |
| Economical speed: | 9 knots |
| Type of fuel: | Marine Gas Oil |
| CARGO CAPACITIES | |
| Deck Cargo: | 300 t |
| Deck Strength: | 7.5 t / m² |
| Clear Deck Area: | 250 m² |
| Fuel Oil: | 520 m³ |
| Fresh Water: | 280 m³ |
| Ballast/Drill Water: | 110 m³ |
| Freezer/Chiller: | 12 m³ / 12 m³ |
| Foam: | 18 m³ |
| Detergent: | 18 m³ |
| PROPULSION SYSTEM | |
| Main Engine: | 2 x Caterpillar 3516B@ 2,375 BHP |
| Main Generator: | 3 x Caterpillar 3408C @ 315 kW |
| Emergency Genset: | 1 x Perkins @ 50 kW |
| Bow Thruster: | 1 x 5 t Tunnel Thruster |
| Steering Gear: | 2 x 35 degree – 5 t |
| Propulsion: | 2 x 4 Bladed CPP in kort nozzles BERG |
| Rudders: | 2 x Conventional Rudder |
| DECK EQUIPMENT | |
| Windlass: | 8 t at 9 m/min for 36 mm diameter chain |
| Bow Anchors: | 2 x 1080 kg HHPA |
| Chains: | 2 x 412.5 m x 34 mm |
| Capstan: | 2 x 5 t @ 15 m/ min |
| Tugger Winch: | 2 x 10 t @ 15 m/ min |
| Deck Crane: | 1 x Electro Hydraulic Crane SWL 5 t @ 10 m |
| DISCHARGE RATES | |
| Fuel Oil: | 60 m³ / hr @ 50 m/head |
| Fresh Water: | 60 m³ / hr @ 50 m/head |
| AUXILLIARY SYSTEM | |
| Oily Water Separator: | 1 x 1 m³ /hr |
| Water Maker: | 1 x 4.9 m³/ day Reverse osmosis |
| Sewage Treatment Plant: | 1 x 25 men per day |
| ACCOMMODATIONS | |
| Berths: | 24 |
| All cabins are fully air-conditioned | |
| FIRE FIGHITING EQUIPMENT | |
| External | |
| FiFi: | FiFi 1 |
| Fire pump: | 2 x 1400 m³/hr at 12 bar |
| Fire monitor: | 2 x 1400 m³/hr at 12 bar |
| Internal | |
| Fixed System in E/R: | CO2 system in engine room |
| Fire Detection System: | All living spaces and engine room |
| TOWING & ANCHOR HANDLING EQUIPMENT | |
| Bollard Pull: | 60 MT |
| Tow/AH Winch: | Double Drum Waterfall Type |
| 1000 m x 56 mm wire rope (Towing) | |
| 1000 m x 56 mm of wire rope (Anchor Handling) | |
| Braking Capacity: | 200 MT |
| Stern Roller: | 6 m & 3.5 m length, 150 MT |
| Shark Jaws: | 300 MT hydraulic retractable |
| Tow Pins: | 2 x 100 MT |
| NAVIGATIONAL /COMMUNICATION | |
| GMDSS: | A1 + A2 + A3 |
| SSB: | 1 x FURUNO FS-2570C |
| GPS Navigator: | 1 x FURUNO GP-80 |
| SART: | 2 x MCMURDO RT9-3 |
| Inmarsat C: | 1 x FURUNO FELCOM 15 |
| VHF Radio: | 2 x FURUNO FM-8500 |
| Navtec Receiver: | 1 x Furuno NX-500 |
| X-Band Radar: | 1 x FURUNO FR-2115 |
| 1 x FURUNO FR-1510 MARK 3 | |
| Echo Sounder: | 1 x FURUNO FE-700 |
| Gyrocompass: | 1 x ANSCHUTZ |
| Autopilot: | 1 x ANSCHUTZ NP-60 |
| Weather Fax: | 1 x FURUNO FAX-207 |
| Speed Log: | 1 x FURUNO DS-80 |
| Magnetic Compass: | 1 x CASSENS & PLATH |
| AIS: | 1 x FURUNO FA-100 |
| Satellite EPRIB: | 1 x MCMURDO E3 |
| LIFE SAVING APPLIANCE | |
| Liferafts: | 4 x 15 persons |
| Lifebuoys: | 8 pcs with buoy lights |
| Life jackets: | 40 pcs |
| Immersion suit: | 3 (exemption JLM) |
| Rescue boat: | 1 x 6 men (rigid) c/w 15 hp |
| 1 x 6 men (inflatable) c/w 25 hp | |
| Air Breathing App.: | 4 Nos. |
| EEBD: | 6 Nos. |
