40 tbp 4-PM FiFi-1 Field Support Vessel
Versatile & multi-functional
2008, BV, 4-point mooring, FiFi-1. Loa 48,0 m, Width 12,5 m. DW: +/-750 ton. Deck cargo: 725 ton, 2 x 1.600 kW, bow thruster. Deckcrane, 34 pax accommodation. WAF. For charter only: Inquire
| General | |
| Built | 2008 |
| Class | BV, I ✠ Hull ✠ Mach, Supply/Utility Vessel, |
| oil product FP>100°C, FiFi-1 water spraying, | |
| unrestricted navigation | |
| Dimensions | |
| Length oa | 48.0 m |
| Width | 12.6 m |
| Depth | 5.2 m |
| Draft | 4.2 m |
| GRT | 1028 |
| Performance / Consumption | |
| Bollard pull | 40 t |
| Service speed | 12.5 knots @ ≈ 12 t/day |
| Eco speed | 11.5 knots @ ≈ 8.5 t/day |
| 4-point mooring | ≈ 0.5 t /day |
| Deck / cargo capacity | |
| Deck area | 164 m2 |
| Deck load | 725 t |
| Deck strength | 5 t/m² |
| Deadweight | 750 t |
| Deck equipment | |
| FiFi-1 monitors | 2 x 1200 m³/h |
| 4-point mooring | 4 x 35t, 1,200 m, x 28 mm |
| Anchors | 4 x 3.0 t Flipper Delta |
| Towing winch | Single drum, 800 m x 42 mm |
| Towing pins | yes |
| Deck crane | 10 t @ 12 m , 14 m max outreach |
| Tugger winches | 2 x 12 t |
| Zodiac | 36 hp o/b engine |
| Oil Rec | Foam & dispersant booms |
| Machinery | |
| Main engines | 2 x Cummins, 1200 kW each |
| Propulsion | 2 x CPP |
| Bow thruster | 1 x 200 kW electric |
| Generators | 3 x Volvo Penta, 250 kW each |
| Port generator | 67 kW |
| Tank / Transfer capacities | |
| Fuel | 240 m³, 70 m³/hr |
| Freshwater | 520 m³, 70 m³/hr |
| Desalination | Max 8 t/day |
| Sludge | 6.3 m³ |
| Accommodation | |
| Cabins | 5 x 1-berth, 15 x 2-berth |
| Other | Mess, galley, sanitary |
