7.000 m³ Hopper Dredger
For Sale: 2009 built 7000 m3 Hopper Dredger, IHC dredge pumps, CCS class, Next Special Survey Nov. 2024. Location: Far East. Enquire
| General | |
| Built | 2009 |
| Class | CCS, ★CSA, Hopper Dredger, |
| dredging within R1, ★CSM, unrestricted | |
| Dimensions | |
| Length | 109 m |
| Beam | 21 m |
| Depth | 8.50 m |
| Draft (dll) | 7.70 m |
| GT | 6,150 |
| Dredging particulars | |
| Hopper volume | 7,000 m³ |
| Deadweight (dll) | 9,250 t |
| Dredging depth | 27 m |
| Dredge pumps | 2 x IHC |
| Suction pipes | 2 x 800 mm |
| Bottom doors | 14 x |
| Bow connection | 750 mm, pump ashore & rainbow |
| Speed (loaded) | 12 knots |
| Machinery | |
| Main engines | 2 x 2,500 kW |
| Propulsion | 2 x FPP in nozzles |
| Bow thruster | 1 x 375 kW |
| Generators | 3 x 500 kW, 1 x 280 kW, 1 x 250 kW |
| Dredge pump engines | 2 x Cat 3516, 1475 kW each |
| Jet pump engines | 2 x 900 kW |
| Deck equipment | |
| Crane aft | 12 t @ 15 m |
| Crane fwd | 8 t @ 16 m |
| Tank capacity | |
| Fuel | 1200 m3 |
| Fresh water | 400 m3 |
| Accommodation | |
| Cabins | For 28 crew |
