2400 m3 Hopper Dredger
Solid IHC designed and built Hopper Dredger, suitable for maintenance dredging, equipped with SWD and Cat engines. Location: China. Enquire
| General | |
| Built | IHC, Early 90-ties |
| Class | IACS |
| Dimensions | |
| Length | 80 m |
| Beam | 16 m |
| Depth | 5.5 m |
| Draft (DLL*) | 4.5 m |
| GT | 2,485 |
| Performance | |
| Hopper volume | 2,400 m3 |
| Deadweight (DLL*) | 3,290 t |
| Speed (ballast/loaded) | 14 knots / 12 knots |
| Fuel consumption | Sailing: 10 m3/day |
| Dredging: 9 m3/day | |
| Machinery | |
| Main engines | 2 x (Wartsila) 8SW280, 1850 kW ea |
| Propulsion | 2 x CPP |
| Bow thruster | 1 x 250 kW |
| Generators | 2 x 750 kW M/E driven |
| 1 x Cat. 3408, 300 kW | |
| 1 x Cat. 3306, 125 kW | |
| Dredge pump engine | 1 x Cat. D335, 375 kW |
| Jet pump engine | 1 x Cat. D335, 320 kW |
| Dredging particulars | |
| Dredge pump | 7,500 m3/h (water) |
| Jet pump | 950 m3/h |
| Dredging depth | 30 m |
| Dredge pipe | 1 x 700 mm |
| Discharge | 2 x 8 double bottom doors |
| Navigation & Communication | |
| GMDSS | A1, A2, A3 |
| Accommodation | |
| Cabines | 10 x 1-berth, 5 x 2-berth |
| Other | Galley, mess, sanitary |
| * DLL | Dredging Load Line / Load Line Exemption |
