Multi Purpose Patrol Vessel
Multi Purpose Shallow Draft Patrol, Intervention, Security Vessel
2003, mono hull, L x b x draft (m): 34.0 x 7.00 x 1,6, Speed: 18/20 knots, propulsion: 2 x 930 kW, fixed props, Slipway with hydraulic stern door, suitable for a 7 meters jet drive RIB. Deck Crane. Government vessel. Well maintained and fully kitted out. Price: Inquire
| General | |
| Built | 2003 |
| Class | LR, 100 A1 SSC, Patrol, Mono, HSC, G2, LMC UMS. |
| Hull / Superstructure | Steel / Aluminium |
| Dimensions | |
| Length | 34 m |
| Beam | 7.2 m |
| Depth | 3.10 m |
| Draft | 1.50 m |
| GT | 197 |
| Performance | |
| Speed | 18-20 knots |
| Machinery | |
| Main engines | 2 x Cat. 3412, 932 kW each |
| Bow thruster | 2 x 44 kW |
| Generators (2011) | 2 x Cummins, 97 kW each |
| Port generator | 1 x Hatz, 23 kW |
| Tank capacities | |
| Fuel | 9.35 m3, (option 34 m3) |
| Fresh water | 3.5 m3 |
| Bilge water | 1.9 m3 |
| Sewage | 1.3 m3 |
| Deck equipment | |
| Hydraulic crane | Effer 3700 2S |
| RIB Slipway | c/w stern door |
| Accommodation | |
| Cabins | 8 crew (16 crew) |
| Other | Galley, mess/dayroom |
| Office, sanitary |
