70 Pax Fast Supply Crewboat / Utility Vessel
Mono hull, fixed props
ABS. L x b x d (m): 38.00 x 8.20 x 3.65. Draft 1.45 m. Speed: 22 knots, 110 m2 deck area, propulsion: 3 x fixed props totalling 4,500 kW. 70 pax + 10 crew. Price: Inquire
| GENERAL | |
| Built: | 2008 |
| Class: | Bureau Veritas – I Hull Mach, Crew boat-Special |
| service Utility Vessel, Unrestricted navigation | |
| DIMENSIONS | |
| LOA: | 38.0 m |
| Beam: | 8.20 m |
| Depth: | 3.65 m |
| Draft (loaded): | 1.45 m |
| CAPACITIES | |
| Cargo Deck Space | 6.50 x 17.0 m (110 m2) |
| Deck Strength | 3 t/m2 |
| Reefer Point | 4 x on deck ( 220 / 440 Vac) |
| Potable Water Tanks | 35 m3 |
| Fuel oil Tanks | 90 m3 |
| Lubrication Oil Tanks | 200 ltr |
| Cargo Weight (max) | 100 t |
| Deadweight (max) | 218 t |
| PROPULSION | |
| Main Engines | 3 x MTU – 12V 396TE74L, 1,500 kW each |
| Generators | 2 x Cummins 6CTBA-3D(M), 135 kW each |
| Propellers | 3 x Fixed Pitch Propeller (FPP) |
| Bow Thruster | Tunnel, 2 tonne thrust |
| Speed / Consumption | Max. 22 knots / approx 950 lt / hr |
| Cruising 20 knots @ 85% MCR / approx 750 lt / hr | |
| Genset app 25 lt / hr | |
| ACCOMMODATION | |
| Cabins | 2 x 1-berth, 2 x 2-berth and 1 x 4-berth |
| Crew | 8 persons |
| Passengers | 70 pax HSC, business Class inclined seat |
| Fully air conditioned | |
| LIFE SAVING EQUIPMENT | |
| Water Curtain | All around accommodation |
| Inflatable Life Rafts | 4 x 50 men |
| Rescue Boat | 6 men x 1 semi Rigid rescue boat c/w 25hp outboard engine |
| Ring Buoys | 8 pc |
| Man over Board Marker | 2 pc |
| Life Jackets / Vests | 88 pc |
| SART | 2 pc |
| EPIRB | 1 pc |
| Line Throwing Apparatus | 1 set (4 projectiles & 4 lines) |
| Scrambling Nets | 2 sets |
| FIRE FIGHTING EQUIPMENT | |
| Fire Extinguishers | As per SOLAS |
| Fireman Outfit | 2 sets |
| Breathing Apparatus | 2 sets |
| External Fire Monitor | 1 x 150 m3/hr @ 40 m |
| NAVIGATION & COMMUNICATION | |
| Radar | 2 sets |
| VHF Radio | 2 sets |
| SSB Radio | 1 set |
| GMDSS VHF Portable Radio | 3 sets |
| Bathometer | 1 set, 1 repeater |
| Auto Pilot System | 1 set |
| Magnet Compass | 1 set |
| Gyro Compass | 1 set, 3 repeaters |
| Intercom system | Phontech with 10 substation |
| DGPS | 2 sets |
| Anemometer | 1 set |
| Thermometer | 1 set |
| Barometer | 1 set |
| Navtex | 1 set |
| Weather Fax | 1 set |
| Echo sounder | 1 set |
| Public Addressor / PA | Phontech with 4 zones |
| OTHER EQUIPMENT | |
| Bilge Pump / Ballast Pump | 50 m3/hr @ 80 m head |
| Fire Pump | 50 m3/hr @ 80 m head |
| Fresh Water Pump | 40 m3/hr @58 m head |
| Anchor Weight | 255 kg, HPP |
| Anchor Windlass | Double Gypsoy Twin Warping Head |
| Tugger Winch | 1 x 5 mt |
| Stove(cooker) | 1 pc |
| Refrigerator | 2 x 100 ltr, 1 x 340 ltr |
| Freezer | 1 x 600 ltr |
| Washing machine | 2 x 10 kg |
| Dryer | 1 x 10 kg |
| Rescue Zones | 2 |
| Hospital owner cabin | 1 |
| Stern Boarding platform | Yes |
