60 Pax Fast Supply Crewboat / Utility Vessel (2 sisters)
Mono hull, fixed props
ABS. L x b x d (m): 40.00 x 7.50 x 3.25. Draft 2.30 m. Speed: 27.8 knots, 114 m2 deck area, propulsion: 3 x fixed props totalling 4,500 bhp. 60 pax + 10 crew. Price: Inquire
| GENERAL | ||
| Built | 2013 | |
| Classification | BV | |
| DIMENSIONS | ||
| Length | 40.0 m | |
| Beam | 7.5 m | |
| Depth | 3.25 m | |
| Draft | 2.30 m | |
| GRT | 240 | |
| CAPACITIES | ||
| Cargo Deck Space | 6.0 m x 19.0 m = 114 m2 | |
| Deck Strength | 2 t/m2 | |
| Reefer Point | 2 x on deck (220/ 40V AC) | |
| Potable Water | 30 m3 | |
| Fuel | 61.8 m3 | |
| Deck cargo | 45 t | |
| Deadweight | 210 t | |
| Light displacement | 103 t | |
| PROPULSION | ||
| Main Engine | 2 x Cummins KTA38 M2, 1,350 bhp each | |
| 1 x Cummins KTA50 M2, 1,800 bhp | ||
| Generators | 2 x Cummins BT 5.9 D(M), 80 kW each | |
| Propellers | 3 x Fixed Pitch Propeller (FPP) | |
| Bow Thruster | Tunnel, 2 ton thrust | |
| Reduction Gear & Ratio | Twin Disc, MG 6690& 6848 SC 2.47:1 | |
| Speed / Consumption | Maximum | 27.8 knots, approx 847 ltr/hr |
| Cruising | 26.1 knots @85% MCR, approx 724 ltr/hr | |
| Economical | 20.0 knots @ 75% MCR, approx 550 ltr/hr | |
| Gensets | approx 25 ltr/hr | |
| ACCOMMODATION | ||
| Cabins | 2 x 1-berth, 2 x 2-berth and 1 x 4-berth | |
| Crew | 10 pax | |
| Passengers | 60 pax Business Class reclined seat | |
| Full Air-conditioned | ||
| LIFE-SAVING EQUIPMENT | ||
| Water Curtain | All around accommodation | |
| Inflatable Life Rafts | 8 x 20 men | |
| Rescue Boat | 6 men x 1 Semi-Rigid c/w 25hp outboard | |
| Ring Buoys | 8 pc | |
| Man Over Board Marker | 2 pc | |
| Life Jackets / Work Vests | 68 pc / 12 pc | |
| SART | 2 pc | |
| EPIRB | 1 pc | |
| Line Throwing Apparatus | 1 set (4 projectiles & 4 lines) | |
| Scrambling Nets | 2 sets | |
| FIRE-FIGHTING EQUIPMENT | ||
| Fire Extinguishers | As per SOLAS | |
| Fireman Outfit | 2 pc | |
| Breathing Apparatus | 2 sets of SCBA | |
| NAVIGATION & COMMUNICATION | ||
| Radar | 2 pc | |
| VHF Radio | 1 set | |
| SSB Radio | 1 set | |
| GMDSS VHF Portable Radio | 3 sets | |
| GMDSS | A1, A2 & A3 | |
| Auto Pilot system | 1 set | |
| Magnet-Compass | 1 set | |
| Satellite Compass | 1 set, 3 repeaters | |
| Intercom system | Uller International Talkback | |
| DGPS | 2 sets | |
| Anemometer | 1 set | |
| Thermometer | 1 pc | |
| Barometer | 1 pc | |
| Navtex | 1 set | |
| AIS System | 1 set | |
| Echo sounder | 1 set | |
| PA system | CMR SPT system 4 | |
| Satellite Mini-M | 1 set | |
| OTHER EQUIPMENT | ||
| Bilge Pump/ Ballast Pump | 30 m3/hr @ 54 m head | |
| Fire Pump | 30 m3/hr @ 54 m head | |
| Fresh Water Transfer Pump | 13.5 m3/hr @ 55 m head | |
| Fuel Transfer Pump | 13.5 m3/hr @ 54 m head | |
| Anchor Weight | 255kg HHP | |
| Anchor Windlass | Double Gypsoy Twin Warping Head | |
| Stove (cooker) | ||
| Dry Store | 4 m2 | |
| Fridge | 4 m2 | |
| Freezer | 3 m2 | |
| Washing machine | 10kg | |
| Dryer | 10kg | |
| Rescue Zone | 2 | |
| Hospital / Owner Cabin | 1 | |
| Stem Boarding Platform | Yes | |
