100 Pax Fast Supply Crewboat / Utility Vessel

Mono hull, fixed props

New. Prompt delivery. IACS class. L x b x d(m): 40.00 x 8.20 x 3.65. Draft 2.00m. Speed: 27 knots cruise with 50 ton deadweight / 18 knots cruise fully laden, 115 m2 deck area, propulsion: 3 x 1,350 kW, fixed props. 100 pax + 10 crew. Price: Inquire

Artikelnummer: E0033 Categorie: Tag:
General
Built 2016
Classification ABS, ✠ A1 HSC Crewboat ✠ AMS
Safety Regulation Class and Flag state requirements
Dimensions
Length oa 40.0 m
Beam 8.2 m
Depth mld 3.65 m
Draft (approx.) 2.0 m
Freeboard 1.65 m
GRT 295
Performance
Service Speed 27 knots, 85% MCR @ 50 t deadweight
Fuel consumption 1,006 l/h 100% MCR
Laden speed 18 knots @ 85% MCR Fully Loaded
Cargo capacity / deck equipment
Deck area 115 m2 (18.0m length x 6.4 m width)
Deck Load 85 t
Deck Strength 2.5 t/m2
Deadweight 190 t
Crane 1.0 t @ 6.0 m
Workboat Inflatable with 25 hp outboard
Helicopter Winching area
Fire Fighting 600 m3/h monitor (optional)
Machinery
Type 4 x Cummins KTA 38-M2, 1012 kW each
Propellers 4 x Fixed Pitch
Bow Thruster 1 x 90 kW
Generators 2 x Cummins 6BT5.9-DM, 91 kW each
Alternators Siemens 1FC2224-4, 2 x 80 ekW
Power Supply 415/240 Volt AC, 50Hz, 3ph + 24 Volt DC
Accommodation
Passenger Capacity 100 Aircraft type economy class seat
Crew 10 berth in 5 cabins, Mess seating for 10 crew
Tank capacities
Fuel Oil 100 m3 (fuel transfer rate @ 23 m3/hr)
Fresh Water 30 m3
Oil pollution tank capacity and control
Dirty Oil Tank 1.0 m3
Oily water separator 0.25 m3/hr
Sewage treatment Hamworthy KSE STC01
Life saving equipment
Life Rafts 6 x 50 pax
Life Jackets 120
Life Buoys 8 x
Rescue Zone Yes
Scrambling Nets 2 units
Other Equipment Pyrotechnics, Line throwing apparatus
Electronics and Controls
GMDSS GMDSS A2
VHF Furuno FM-8900S + 2 hand held
SSB Radio Furuno FS-1575 + Icom IC-M710 (non GMDSS)
Satcom/Fax Inmarsat Fleet Broad Band felcom-250
GPS Furuno GP-170
Echo Sounder Furuno FE-800
Gyro Compass Anschutz STD-22
Autopilot system Anschutz NP-60
Navtex Furuno NX700B
Marine Radar 2 x Furuno FAR2117
EPIRB ACR RLB-38
SART ACR Pathfinder3
AIS Furuno FA-150
PA/Intercom System Vingtor Pro-700
Search Lights 3 x Karldose, 1000W
Chart Plotter Garmin GPSMAP5012
