Fast Crew Supplier, DP-1 FiFi-1 (2 sisters)
2013, Sea Axe bow mono hull, DP-1, FiFi-1 waterspray, l x b x draft (m): 53.25 x 10.10 x 3.20, Speed: 22 knots, propulsion: 4 x 1,118 kW, fixed props. 50 pax + 12 crew. ME Gulf region. For Sale or Charter: Inquire
| General | |
| Built | 2013 |
| Hull / Superstructure | Steel / Aluminum |
| Class | BV, I ✠ Hull • Mach Special Service, |
| Fast Utility Vessel, Sea Area 4, | |
| Dynapos AM, Fire Fighting Ship 1 | |
| Dimensions | |
| Loa | 53.5 m |
| Width | 10 m |
| Depth | 4.7 m |
| Draft | 3.2 m |
| Capacities | |
| Fuel Oil | 170 m3 |
| Fresh Water | 28.5 m3 |
| Fresh Water cargo | 173 m3 |
| Cargo Deck Area | 240 |
| Max. Deck Load | 2.5 t/m2 |
| Crew | 12 |
| Pax (ex-crew) | 50 |
| Performance | |
| Speed | 22 knots |
| Propulsion system | |
| Main Engines | 4 x Cat 3512C TA, 1118 kW each |
| Gearboxes | 4 x Reintjes ZWVS 730/1 |
| Propulsion | 4 x fixed pitch propellers |
| Bow Thrusters | 2 x 85 kW, electrically driven |
| Electrical Equipment | |
| Network | 24V DC, 240/415V 60 Hz AC |
| Generator sets | 3 x Cat C4.4, 99 kW each |
| Deck Lay-out | |
| Anchor Equipment | 1 x 184 kg HHP |
| Fendering | Aluminum fender on deck level, |
| heavy duty rubber- and tire fenders | |
| Life saving equipment | |
| Life Buoys | 4 |
| Life Jackets | 88 |
| Life Rafts | 4 x for min. 88 persons |
| Fire Extinguishing | Hand operated fire extinguishers. |
| Fixed FiFi system in ER (Novec 1230) | |
| Fast Rescue Boat | Fast RSQ 700, speed 30+ knots |
| in A-frame davit | |
| Auxiliary Equipment | |
| ER Ventilation | 72,000 m3/hr |
| General Service Pumps | Electrically driven, 400 V Azcue CA 50 |
| Fuel Cargo Pump | 1 x 415 V 70 m3/hr at 6.3 bar |
| Fresh Water Cargo Pump | 1 x 415 V 70 m3/hr at 6.3 bar |
| Accommodation | |
| Below Main Deck | Crew cabins, pantry and messroom |
| Main Deck | 50 seats, luggage storage and 2 toilets |
| Air-Conditioning | Yes, wheel house and accommodation |
| Nautical and communication equipment | |
| Searchlight | 2 x 1000 MP Pesch |
| Echo Sounder | Alphatron, Alphasounder |
| Radar | 2 x JRC, JMA 5206 |
| AIS | |
| GPS / DGPS | Veripos / JRC 7800 |
| Naxtex & Airs | JRC, NCR-333 & JRC, JHS-182 |
| Internal Communication | Intercom, loudhailer and CCTV system |
| External Communication | GMDSS A3 |
| Autopilot | Alpha seapilot MFC |
| Gyro Compass | Alpha minicourse |
| Dynamic Positioning | Alphatron / Navis, (Dynapos AM) |
