40 tbp AHT
Ocean & Coastal Towage, Anchor Handling & Supply
2009, BV class, l x w x d (m): 36.0 x 10.9 x 5.0. Draft 4.0 m, 2 x Cummins KTA-50, 1,600 bhp each, Towing/AH winch waterfall configuration. Sternroller and other AH related equipment. Inquire
| GENERAL | |
| Built : | 2009 |
| Class : | BV, I ✠ Hull ✠ Mach Tug, Special Service, Anchor |
| Handling Vessel, Unrestricted Navigation | |
| PRINCIPAL DIMENSIONS | |
| Length: | 36.0 m |
| Breadth Mld : | 10.4 m |
| Depth Mld : | 5.0 m |
| Design Draft : | 4.0 m |
| GRT: | 450 |
| Deck Strength : | 2.5 t/m² |
| Deck Space : | 114 m² |
| PERFORMANCE AND CONSUMPTION | |
| Bollard Pull : | 40 t |
| Maximum Speed : | 12 knots |
| Economical Speed : | 9.5 knots |
| Fuel Consumption : | 10.5 t/day |
| MACHINERY | |
| Main Engine : | 2 x Cummins KTA 50-M2, 1200 kW each |
| Generator : | 2 x Cummins 240KW each |
| Gearbox : | Reintjes Gearbox Ratio 5.95:1 |
| Bow Thruster : | 3 Tons, ATB Sever |
| Propulsion System : | 4 Blade FPP with fixed nozzles |
| DECK MACHINERY & EQUIPMENT | |
| Anchor Windlass : | 1 x Electric-Hydraulic anchor windlass |
| c/w double gypsy drum | |
| Anchor : | 2 x 570 kg stockless anchor |
| Anchor Chain : | 2 x 24 mm studlink chains |
| Tugger Winch : | 1 x 5 t @ 15 m/min |
| Hydr. Capstan : | 1 x Hyd. Capstans, 5 tons @ 15 m/min |
| Deck Crane : | 1 x Hyd., 1.5 t @ 9 m radius |
| Towing Winch : | 1 x Hyd. double drum |
| Wire : | 600 m x 44 mm each |
| Line Pull : | 40 t, 1st layer |
| Brake Holding : | 80 t, 1st layer for each drum |
| Tow Pin : | 1 x 200 t |
| Shark Jaw : | 1 x 200 t |
| Stern Roller : | 1 x 150 t S.W.L. |
| TANK CAPACITY | |
| Fuel : | 299 t |
| Fresh Water : | 100 t |
| Lube Oil : | 3.0 t |
| ACCOMODATION | |
| Cabins : | 2 x 1-berth = 2 men |
| 1 x 2-berth = 2 men | |
| 3 x 4-berth = 12 men | |
| Total | 16 men |
| NAVIGATION & COMMUNICATION EQUIPMENT | |
| Radar, Magnetic Compass, Echo Sounder, DGPS, Autopilot, GMDSS, MF/HF, VHF-DSC, Radar responder, EPIRB, Navtex Receiver, Inmarsat-C, SSB, SART, AIS | |
| FIRE-FIGHTING EQUIPMENT | |
| FiFi System | 600 m3/hr monitors |
| As per SOLAS requirements | |
| LIFE SAVING EQUIPMENT | |
| As per SOLAS requirements | |
