54 tbp Shallow Draft FiFi-1 AHT
Towing, Anchor Handling, Shallow Water operations, Dredge/Field Support
2007, Lloyds Register. l x w x d (m): 35.00 x 11.50 x max. draft 3.15 m. 3 x Cummins, 1235 kW each, 54 tbp. knuckleboom crane: 185 tonmeter. For charter only. Location ME gulf. Enquire
| General | |
| Built | 2007 |
| Class | Lloyds, +100 A1 tug, fire fighting Ship 1 |
| (2400m³/h) Ice Class 1B FS, ALMC UMS | |
| Dimensions | |
| Length | 35 m |
| Beam | 11.5 m |
| Draft | 2.4 m (min.) 3.15m (max.) |
| GRT | 477 |
| Performance | |
| Bollard pull | 54.5 t |
| Speed | 13 knots |
| Machinery | |
| Main Engines | 3 x Cummins KTA50, 1235 kW each |
| Propulsion | 3 x FPP in nozzles |
| Deck equipment | |
| AH/Towing winch | 50 t double drum waterfall |
| Towing drum | 550 m x 52 mm wire |
| AH drum | 380 m x 48 mm wire |
| Storage reel | Spare tow wire |
| Tugger winch | 1 x 9 t |
| Crane | 185 tm, 32.5 t at 4 m, 6.35 t at 17 m |
| Tow pins | 3 x with hold down hook |
| Stern roller | 50 tonne |
| Towing hook | tow hook, , |
| Aft deck | Timber covered with container fixing points |
| Fire-fighting | 2 x 1200 m3/h per hour |
| FiFi monitors | 2 x remote controlled |
| Tank Capacities | |
| Fuel | 215 m3 |
| Fresh Water | 135 m3 |
| Navigation and communication equipment | |
| GPS compass, DGPS, 2 x Radar, Echo sounder, Doppler log, AIS, Navtex, electronic chart, autopilot, GMDSS (A3), Inmarsat C, MF/HF radio, VHF radios, EPIRB and SART, SatCom | |
| Accommodation | |
| Cabins | 10 for 18 crew |
| Heated and air conditioned | |
