45 tbp ASD berthing tug (2 sisters)
2004, solid design, well maintained 45 tbp ASD escort / berthing / mooring tug. L x B x D x draft (m): 29 x 9.0 x 4.7 x 3.8. FiFi capability. Location: SE Asia. Enquire
| General | |
| Built | 2004, Singapore |
| Class | LR, ✠ 100 A1 ✠ LMC (firefighting capability) |
| Dimensions | |
| Length oa | 29 m |
| Beam | 9.0 m |
| Depth mld | 4.7 m |
| Draft | 3.8 m |
| GRT | 250 |
| Performance | |
| Bollard pull | 45 t |
| speed | 12 knots |
| Deck equipment | |
| Escort / berthing winch | Split drum. Hold: 110 t, |
| Pull: 2.5 t at 25 m/min, slack @ 50 m/min | |
| Towing hook | Yes |
| Machinery | |
| Main engines | 2 x Niigata 6L22HLX 1323 kW each |
| Propellers | 2 x Niigata ZP-21 RC FPP |
| Generators | 2 x Cummins 6CT 8.3D(M) 95 kW each |
| Sewage system | Yes |
| Fire-Fighting / Anti-Pollution Equipment | |
| Pump | 1 x 1400 m3/h Nijhuis HGT1, c/w water curtain |
| Monitor | 2 x 600 m3/h Skum FJM150 foam/water |
| Tank Capacities | |
| Fuel oil | 114.5 m³ |
| Freshwater | 34.0 m³ |
| Dispersant | 2.3 m³ |
| Foam | 6.4 m³ |
| Radio and Navigation equipment | |
| Radar | Furuno 1832 mk 2 |
| SSB receiver | Furuno FS 1503 |
| VHF | Furuno FM-8500 |
| Echo sounder | Furuno GP-1650WF |
| EPIRB | McMurdo E3A |
| Accommodation | |
| Cabins | 1 x 2-berths, 2 x 4-berths |
| Fully air-conditioned | |
