52 tbp ASD Escort FiFi-1 (2 sisters)
Terminal and Escort
2015, Aft towing winch 55 ton, brake holding 110 ton, fwd winch 55 ton, brake holding 115 ton. Price (en-bloc or individual): Inquire
| GENERAL | |
| Year Built | 2015 |
| Location Built | China |
| Classification | Bureau Veritas |
| Class Notation | BV: I, + Hull, + Mach, Tug, Fire-Fighting ship 1 |
| DIMENSIONS | |
| Length oa | 29.00 m |
| Width | 10.50 m |
| Depth | 4.96 m |
| Draft (Operations) | 4.00 m |
| TONNAGE | |
| GT / NT | 351 / 105 |
| Displacement | 665 ton |
| Lightship | 480 ton |
| PERFORMANCE | |
| Bollard Pull | 52 ton |
| Speed | 11.5 Knots |
| TANK CAPACITIES | |
| Fuel Oil | 162 m3 |
| Fresh Water | 33 m3 |
| Foam Tank | 7.2m3 |
| Dispersant Tank | 7.2m3 |
| MAIN MACHINERIES | |
| Main Engines | 2 x Niigata 6L26HLX |
| Total BHP | 2 x 1,471kw @750 Rpm |
| Propulsion | 2 x Z-peller-ZP31, Azimuth fixed pitch propellers |
| Aux Engine | 2 x Volvo Penta @ 168kw |
| Alternators | 1 x 40kw@1500rpm, China |
| DECK EQUIPMENT | |
| Fwd Towing winch | 5T @ 20m/min, low speed @ first layer |
| Brake Holding | 115T @ first layer |
| Drum Capacity | 1 x 12” Circ x 200 m working towing rope |
| Aft towing winch | 55T Hydraulic Towing winch |
| Brake Holding | 115 tonnes (1st layer) |
| Drum Capacity | 1 x 700m of 46mm dia |
| Towing Hook | 55T with remote pneumatic release |
| Deck Crane | 1 x SWL 435kg. Outreach: 9.4M |
| Tugger winch | 5T Hyd Tugger winch, dia 28mm x 200m |
| EXTERNAL FIRE FIGHTING & OIL SPILL EQUIPMENT | |
| Fire Pump-FiFi 1 | 1 x 2,800 m3/hr @120 mwc |
| Fire Monitors | 2 x 1,200 m3/hr with remote control |
| Oily Water Separator | 0.5 m3/hr |
| Dispersant System | 1 x dispersant pump c/w P & S Veejet nozzle |
| NAVIGATION & COMMUNICATION EQUIPMENT (A1 + A2 +A3) | |
| Radar | Furuno FAR2117BB |
| DGPS | GP-150 |
| Inmarsat C | 2 X Furuno Felcom 18 |
| MF/HF | Furuno FS 1575 |
| AIS | Furuno FA-150 |
| Speed Log | Furuno DS-80 |
| Echo Sounder | Furuno FE-800 |
| VHF Radio Telephone | 2 x Furuno FM-8900S |
| Navtex Receiver | Furuno NX-700A |
| Sat Compass (THD) | Furuno SC-50 |
| BNWAS | Furuno BR-500 |
| ACCOMMODATION | |
| Complement | 10 men |
| Cabins Total | 2 x 1-men cabins and 2 x 4-man cabin |
