75 tbp DP-1 FiFi-1 AHTS (multiple sisters) (priced to sell)
2007/2008, ABS class, 75 tbp, DP-1, FiFi-1, AHTS. Multiple sisters available. Med, WAF & ME. Inquire
| General | |
| Built | 2007/2008 |
| Class | ABS, ✠A1, Towing Vessel, Fire Fighting Vessel Class 1,  , ✠AMS, DPS-1 |
| Dimensions | |
| Length oa | 60.0 m |
| Beam | 16.0 m |
| Depth | 6.0 m |
| Draft | 4.85 m |
| GRT | 1750 |
| Performace | |
| DP-1 | Kongsberg, cPOS, DGPS |
| Speed | 13 knots |
| Bollard pull | 75 ton |
| Deck/load particulars | |
| Deadweight | 1,800 t |
| Deck area | 400 m² |
| Deck load | 500 t |
| Machinery | |
| Main engines | 2 x Yanmar 8N280M-SV, 2205 kW each, 720 rpm |
| Propellers | CPP in nozzles |
| Bow thruster | 1 x 820 kW |
| Stern thruster | 1 x 320 kW |
| Shaft Gen. | 2 x Leroy Somer, 600 kW each |
| Generators | 2 x Cat. 3408, 450 kW each |
| Deck Equipment | |
| AH/Towing winch | Waterfall, 2 x drum 150 t pull, 200 t brake each |
| Storage drum | |
| Tugger winch | 2 x 10 ton |
| Shark jaw | 300 t |
| Capstan | 2 x 5 t |
| Stern roller | 3.5 m x 1.5 m, 200 t |
| FRC | 220 hp inboard |
| Crane | 1.1 t @ 7.0 m, knuckle boom |
| Tank Capacities | |
| Drill water /Ballast | 800 m³ |
| Fuel oil | 550 m³ |
| Potable water | 300 m³ |
| Liquid mud | 230 m³ |
| Dry bulk | 170 m³ |
| Foam | 22 m³ |
| Fire Fighting (FiFi-1) | |
| Pumps | 2 x 1500 m³/h |
| Monitors | 2 x 1200 m³/h |
| Waterspray | Yes |
| Accommodation | |
| Air-conditioned | |
| Cabins | 4 x 1-berth, 5 x 2-berth & 3 x 4-berth, total 26 persons |
| Other | Hospital, Meeting room, |
| Galley, Messroom, Lounge, Laundry, Cold-, Freeze- and Dry-storage | |
