80 tbp Shallow-draft FiFi-1 AHT
2001 built, 80 tbp, shallow draft AHT, medium speed engines, Full Anchor handling capability, FiFi-1 capability and accommodation from 20 crew and pax. Present location ME Gulf. Enquire
| General | |
| Built | 2001 |
| Class | BV, l ✠ Hull ✠ Mach, Tug-Special |
| Service, AH Tug, Unrestricted | |
| Dimensions | |
| Length | 45.0 m |
| Beam | 11.6 m |
| Depth | 5.0 m |
| Draft | 4.0 m |
| GT | 680 |
| Performance | |
| Speed (max) | 14 knots |
| Speed (service) | 11 knots |
| Consumption | 8 t/24h free running, |
| 14 t/24h towing | |
| Bollard Pull | 80 t |
| Deck & Cargo capacity | |
| Deadweight | 500 t |
| Deck area | 165 m2 |
| Deck cargo | 250 t |
| Machinery | |
| Main Engines | 2 x Wartsila 6L26, 2000 kW each |
| Generators | 2 x 230 kW + 1 x 160 kW |
| Bow Thruster | 1 x 6 t, 460 kW |
| Propulsion | 2 x CPP in nozzles |
| Deck equipment | |
| AH / towing Winch | 180 t, DD Waterfall |
| 110 t @ 6 m/min, 30 t @ 40 m/min | |
| Wires | 915 m x 58 mm |
| Stern Roller | 250 t, 3.5 m x 2.0 m |
| Shark Jaws | 300 t |
| Towing Pins | 100 t |
| Tugger winch | 2 x 10 t |
| Crane | 6.5 t @ 3 m, 2 t @10 m |
| Tank / Transfer capacities | |
| Marine Gas Oil | 423 m3, 1 x 50 m3/h @ 60 m |
| Potable Water | 131 m3, 1 x 50 m3/h @ 40 m |
| Fire fighting | |
| Class | FiFi-1 |
| Pumps | 2 x 1,500 m3/h at 14 Bar |
| Monitor | 2 x 1,200 m3/h, 120 m |
| Safety equipment | |
| Life Rafts | 2 x 25 Men, 2x 12 Men |
| Rescue Boat | 6 Persons Diesel Driven |
| Silencers | c/w spark arrestors |
| H2S System | Fixed, 4 Channel Detectors |
| Navigation & Communication | |
| GMDSS (A3), 2 x Radar, Gyro, Auto Pilot, DGPS, | |
| Echo Sounder, Navtex, EPRIB, 2 x SART, ECDIS | |
| Accommodation | |
| Cabins | 2 x 1-berth, 9 x 2-berth |
| Other | Galley, 2 x mess, sanitary facilities |
| Laundry, fully air-conditioned | |
