50 tbp FiFi AHTS
2013, BV. Loa 56.0 m, width 13.8 m, depth 5.50 m, max draft 4.30 m. DW 1,000 tons. Deck Area 290 m2. Location: Far East. Inquire
| GENERAL | |
| Built: | 2013 |
| Class: | BV, I + Hull, + Mach, Tug-Supply vessel-Special service / |
| Anchor Handling Vessel, Unrestricted navigation | |
| + MACH | |
| DIMENSIONS | |
| Length: | 56.00 m |
| Breath: | 13.80 m |
| Depth / Draft: | 5.50 m / 4.30 m |
| GRT: | 1,180 |
| Deadweight: | 1,000 tons |
| Deck loading: | 5 t/m2 |
| Deck Area: | 290 m2 |
| PERFORMANCE | |
| Max Speed: | 12 knots |
| Bollard Pull: | 50 ton |
| MACHINERY | |
| Main Engine: | 2 x Caterpillar 3516C, 2100 bhp each |
| Main Generator: | 3 x Caterpillar C18, 275 kW each |
| Harbour Generator: | Cummins 50kW |
| Bow Thruster: | 5 tonnes |
| Propulsion: | 2 x FPP |
| DECK EQUIPMENT | |
| AH / Towing Winch: | 150 tonnes line pull |
| Wire Rope: | Tow wire: 50mm x 1000m |
| Tugger Winch: | 2 x 10T @15m/min |
| Stern Roller: | 1.6 m x 5m (SWL 200tonnes) |
| Capstans: | 2 x 5 tonnes @15m/min |
| Sharkjaw / Towpin: | 200 tonnes Hydraulic |
| Tow Wire: | 1000 m x 50mm |
| Crane: | 2 tonnes @ 6.5m |
| TANK CAPACITY | |
| Fuel Oil: | 600 m3 |
| Fresh Water: | 420 m3 |
| Mud: | 150 m3 |
| Dry Bulk Cement: | 113 m3 |
| Foam tank: | 8 m3 |
| Dispersant tank: | 12 m3 |
| ACCOMMODATION | |
| Cabin: | 2 x 1-berth, 3 x 2-berth, 8 x 4-berth |
| Total: | 40 men |
| SAFETY EQUIPMENT | |
| Fire-fighting: | 1 x 1500 m3/hr fire pump |
| Monitors: | 2 x 600 m3/hr |
| Rescue Boat: | 1 x 6 men, 25 HP |
| Life Raft: | 6 x 20 men |
| NAVIGATION / COMMUNICATION EQUIPMENT | |
| Radar: | 2 x JRC / FURUNO |
| Echo Sounder: | 1 x JRC / FURUNO – 200 kHz |
| AIS: | 1 x JRC / FURUNO – FA150 |
| GPS: | 1 x JRC/ FURUNO |
| Auto Pilot: | 1 x Robertson / Anschutz |
| Speed Log: | 1 x JRC / FURUNO |
| Gyro Compass: | 1 x JRC / FURUNO |
| Magnetic Compass: | 1 x SAURA MR – 150A |
| Sat Phone/Fax/Email: | Fixed |
| Inmarsat C: | 1 x FURUNO |
| SSB: | Fitted |
| VHF: | 2 units Fitted |
| Navtex: | 1 x JRC / FURUNO – 518 kHz |
| EPIRB: | 1 x E3 McMurdo |
| SART: | 2 x McMurdo – 9 Ghz |
| GMDSS: | A3 |
| PA System: | Fitted |
| Speed Log: | 1 x JRC / FURUNO |
