400 mm Suction Dredger
2019 EU built demountable Suction Dredger ideal for sand pit production works, with a dredging depth of 12 m, a relatively high dredge pump capacity and jet pump. Optionally available HDPE pipes and floaters. Location SW Europe. Enquire
| General | |
| Built | 2019 |
| Type | Demountable Suction Dredger |
| Dimensions | |
| Length over all | 27.5 m |
| Length incl. side pontoons | 20.0 m |
| Beam incl. side pontoons | 6.5 m |
| Depth | 1.5 m |
| Draft | 1.0 m |
| Weight | 50 t |
| Dredging particulars | |
| Dredging depth max | 12 m in standard conf. |
| Suction / Delivery pipe | 400 mm / 450 mm |
| Spuds | 2 x |
| Dredge pump | 1750 m3/h @ 4.5 bar (water) |
| Jet pump | 300 m3/h @ 6 bar |
| Automation | |
| Dredging control | Trimble Marine |
| Other | VHF, GPS, Plotter and Max Sea |
| Optional | |
| HDPE pipe line | ID 450 mm, PN10 flanged |
| Floaters |
