53 tbp ASD tug
1999, BV class, Damen 3110 versatile 53 tbp ASD tug, 2 x Cat. 3516, FiFi monitors: 2 x 600 m³/h top of mast mounted. 10 crew accommodation. Presently operational WAF. Enquire
| GENERAL | |
| Built | 1999 |
| Class | BV, I ✠ Hull ✠ Mach Tug, Unrestricted navigation, |
| ✠ UT-UMS (SS) | |
| DIMENSIONS | |
| Length over all | 30.8 m |
| Beam | 10.2 m |
| Draft | 4.75 m |
| GT | 305 |
| PERFORMANCE | |
| Bollard pull | 53 t ahead / 51 t astern |
| Speed ahead | 13 knots (maximum) |
| MACHINERY/PROPULSION | |
| Main engines | 2 x Caterpillar 3516B TA, 1566 kW each |
| Propulsion | 2 x fixed pitch ASD propeller |
| TANK CAPACITY | |
| Fuel oil | 140 m³ |
| Potable water | 19 m³ |
| Foam | 24 m³ |
| DECK EQUIPMENT | |
| Fwd winch | Single drum – 135 t. brake load Line pull 25 t. @ 10 m/min |
| Aft winch | Single drum – 135 t. brake load Line pull 25 t. @ 10 m/min |
| Towing hook | Pneumatic, quick release, 65 t SWL |
| NAVIGATIONAL AND COMMUNICATION EQUIPMENT | |
| Magnetic compass | KH Observator Mk3 |
| Echo sounder | Furuno FCV-612 |
| VHF | Furuno FM-8500 |
| Radar | Furuno FR-7062 |
| GPS | Furuno GP-80 |
| OTHER EQUIPMENT | |
| Fire-fighting monitors | 2 x 600 m³/hr |
| Waterspray | Yes |
| Crane | 10 t SWL @ 4.5 m. outreach |
| ACCOMMODATION | |
| Cabins | 2 x 1-berth + 2 x 4-berth |
