77 tbp Escort FiFi-1 ASD Tug (2 sisters)
Harbour, Offshore Terminal, Escort, FiFi-1
2011, BV, Loa 32.0 m, Beam 13.0 m, 485 GT, TBP 77 ahead / 70 astern, Fwd double drum 250 ton brake, Aft single drum 250 ton Brake, FiFi-1, monitors 2 x 1,200 m³/h, 9 berth accommodation. WAF. Inquire
| GENERAL | |
| Built | 2011 |
| Class | BV, 1 +Hull, Mach, Escort Tug – Firefighting ship 1 |
| – water spraying, Unrestricted navigation, AUT-UMS | |
| DIMENSIONS | |
| Length over all | 32.0 m |
| Beam over all | 13.0 m |
| Maximum draft | 5.95 m |
| GRT | 485 |
| MACHINERY/PROPULSION | |
| Main engines | 2 x RR Bergen C25:33L8P, 2400 kW each |
| Propulsion | 2 x controllable pitch ASD propeller |
| Bow thruster | x kW |
| PERFORMANCE | |
| Bollard pull | 77 t |
| Speed ahead | 13 knots |
| Speed (eco) | 9 knots |
| TANK CAPACITY | |
| Fuel oil | 200 m³ |
| Potable water | 66 m³ |
| Foam | 14 m³ |
| ACCOMMODATION | |
| Cabins | 9 persons |
| Air-conditioned | |
| DECK EQUIPMENT | |
| Forward winch | Hydraulic Render-recovery |
| Double drum – 250 t brake load | |
| Line pull 44 t @ 27 m/min. on 2nd layer | |
| Aft winch | Hydraulic, Single drum – 250 t brake load |
| Line pull 50 t @ 10.5 m/min. on 2nd layer | |
| Towing hook | Mampaey, quick-release, 100 t SWL |
| NAVIGATIONAL AND COMMUNICATION EQUIPMENT | |
| Magnetic compass | Cassens & Plath Kotter type |
| Echo sounder | Furuno F-700 |
| VHF | Sailor RT5022/BLK |
| Radar | Furuno FAR 2117 |
| GPS | Furuno GP-150 |
| OTHER EQUIPMENT | |
| Fire-fighting monitors | 2 x 1200 m³/hr |
| Crane | 3.6 t SWL @ 2.74 m outreach |
