100 tbp ASD FPSO FSV
FPSO Support, AHT, Escort, Offshore Terminal, FiFi-1, Waterspray, Oil Rec
2006. BV. L x B(m): 49.5 x 15.0: Fully equipped. 22 men accommodation Inquire
| GENERAL | |
| Built | 2006 |
| Class | BV, 1 + Hull + Mach, + AUT-UMS, tug, unrestricted |
| navigation FiFi-1, water spraying, oil recovery | |
| DIMENSIONS | |
| Length overall | 49.50 m |
| Beam overall | 15.00 m |
| Depth | 6.75 m |
| Draft | 5.60 m |
| Deadweight | 1,270 t |
| Free cargo deck space | 210 m² |
| Deck cargo load | 200 tons |
| Deck strength | 5 t/m² |
| GRT | 1,380 |
| PERFORMANCE | |
| Bollard pull | 100 ton |
| Speed | 13.5 knots |
| MACHINERY | |
| Main engines | 2 x MAK 9M25, 3000 kW each |
| Propellers/Rudders | 2 x Schottel SRP 3030 ASD CPP in kort nozzles |
| Bow thruster | 1 x CPP tunnel, 350 kW |
| Generators | 2 x 250 kW + 1 x 580 kW |
| Harbour generator | 1 x 94 kW |
| DECK EQUIPMENT | |
| AH / Towing winch | 1 x 150 t pull, 350 t brake, waterfall conf. |
| 2 x 1,000 m x 64 mm | |
| Fwd winch | 1 x 75 t pull, 250 t brake, double drum, |
| 1 x 350 m x 64 mm, 1 x 250 m x 800 mm | |
| Tugger winch | 2 x 10 tons |
| Capstan | 2 x 5 tons |
| Towing pins | 1 x 350 tons |
| Shark jaw | 1 x 350 tons |
| Stern roller | 1 x 4.50 m x 2.30 m, 200 tons |
| Towing hook | 120 tons |
| Deck crane | 1 x 2 tons @ 15 m |
| Bow fender | 400 mm cyl. upper & 400 mm W block lower |
| FPSO hose flushing | 2 x 14” valved |
| FIRE-FIGHTING FiFi-1 | |
| Monitors | 2 x 1,200 m3/hr each |
| Pumps | 2 x 1,500 m3/hr each |
| Water/Foam throw | 75 m |
| Deluge system | Self-protecting water spray |
| STAND-BY RESCUE EQUIPMENT | |
| Rescue zone | each side |
| Scrambling nets | 2 x, one on each side |
| Rescue craft | 1 x Norsafe with davit |
| ANTI-POLLUTION | |
| Dispersant pump | 1 x 35 m3/hr with 6 % diluted dispersant |
| Dispersant booms | 2 x 7 m with 5 spray nozzles |
| Dispersant tank | 1 x 26 m3 |
| Oil recovery capacity | 116 m3 |
| CARGO TANK CAPACITIES | |
| Fuel oil | 576 m3 |
| Potable water | 128 m3 |
| Ballast/drill water | 528 m3 |
| Lub oil | 10 m3 |
| Foam | 23 m3 |
| ACCOMMODATION | |
| Cabins | 6 x 1-berth, 8 x 2-berths |
| Hospital | |
| Other common spaces | 1 x Mess room, 2 x day rooms, sanitary spaces, stores. |
| Fully air-conditioned | |
| COMMUNICATION | |
| GMDSS (A3) complete | |
| Sat phone iridium | |
| Sat phone & data, inmarsat fleet 55 | |
| Local area network, 3x computers interfaced to inmarsat | |
