SSV, DP1, 4-P Mooring

Versatile & multi-functional

2013, ABS, DP-1, FiFi-1. Loa 59,0 m, Width 15,0 m, Depth 6,1 m. DW: +/-1.450 ton. Deck cargo: 500 ton, Z-peller drive, 2 x 1.550 kW, bow thruster, 4-point mooring. Deckcrane, 50 pax accommodation. ME Gulf. Price: Inquire

SKU: B0024 Categorías: , , Etiqueta:
PRINCIPAL PARTICULARS
Year Built 2013, China
Class ABS
Notation +A1 E «Offshore Support Vessel, Fi Fi Class 1 + AMS + DPS 1
GT / NT 1,671 / 501

DIMENSIONS
Length Overall 59.25 m
Length Waterline 56.00 m
Breadth Moulded 15.00 m
Depth Moulded 6.10 m
Draft 4.60 m

CARGO CAPACITIES
Deadweight 1,450 mt
Deck Cargo 500 mt
Deck Area 350 m2
Deck Strength 7t/m2
Fuel Oil 880 m3
Fresh Water 400 m3
Water Ballast/Drill Water 1,000 m3
Dispersant 13 m3
Foam 13 m3
Freezer 10 m3
Cooler 10 m3
DISCHARGE CAPACITIES
Fuel Oil 1 x 150 m3/hr @ 60m head
Fresh Water 1 x 100 m3/hr @ 75m head
Drill Water 1 x 100 m3/hr @ 75m head
Bilge/Ballast 2 x 75 m3/hr @ 40m head

MACHINERY
Main Engines 2 x 2,200 BHP Wartsila 8L20
Main Generators 3 x 350 kW Diesel Driven, 415V/3Ph/50Hz
Emergency Generator 1 x 80 kW
Propellers 2 x Azimuth Thruster Controllable Propeller Wartsila LIPS CS 225-S/WN – K
Rudders Z Propeller
Bow Thruster 1 x 350 kW , 5 T Thrust
Steering Gear Wartsila Z – Peller

SPEED
Max. Speed 12.0 knots
Economical Speed 10.0 knots
Type of Fuel Marine Gas Oil
Consumption Economy: approx. 8 mt / 24 hrs @ 85% MCR
Maximum : approx. 14 mt / 24 hrs @ 100% MCR

ACCOMMODATION
1 men Cabins 4
2 men Cabins 5
4 men Cabins 9
Total: 50
Hospital 1 bed
All cabins fully air-conditioned with en suite wash rooms.

RADIO & NAVIGATION EQUIPMENT
GMDSS: Area 3
1 x SSB
2 x Inmarsat C
2 x VHF
1 x Navtex Receiver
2 x SART
1 x EPIRB
3 x VHF Portable radios
2 x Radar
1 x Echosounder
1 x DGPS
1 x Gyrocompass
1 x Autopilot
1 x Magnetic Compass
1 x Weather Fax Receiver
1 x Speedlog
1 x Wind Indicator
1 x AIS
1 x PA/Talkback System
1 x Kongsberg Joystick Control
1 x Self Powered Telephone
 DP-1 – Konsberg

FIRE FIGHTING & ANTI POLLUTION EQUIPMENT
FIFI System Class 1
Pump 2 x 1,500 cbm/hr @ 14 bar
Monitors 2 x 1,200 cbm/hr @ 12 bar (with remote control)
One monitor fitted with double barrel for foam discharge
1 x Water Spray Curtain round the Hull & Deckhouse
Engine room water spray system: Seaplus, South Korea
Fire Extinguishing System
Engine Room CO2 system
12 x fire hydrants and fire extinguishers as Class requirements
2 x fireman outfits
4 x fire blankets for engine room and galley
1 x BA recharging compressor of 75 ltr/min @ 200 bar
Life Saving
6 x 25 men Inflatable Life rafts
8 x Lifebuoys
60 x Lifejackets
1 x Rigid Inflatable Rescue Boat for 6 persons (with outboard motor)

AUXILIARY EQUIPMENT
1 x Sewage Treatment Plant suitable for 50 men
1 x 10T/day Reverse Osmosis Fresh Water Maker
1 x Oily Bilge Water Separator
1 x FRC 15 man with diesel inboard engine c\w launch recovery davit
