750 mm (30″) Cutter Suction Dredger
Recent built, Length: 65,00 m, Width: 17,00 m, Depth: 4,20 m. Total installed power: 5.750 kW. Location: Western Europe. Price: Inquire
| Length o.a. | 75,00 – 96,00 m (depending on configuration) |
| Length o.a., pontoon | 65,00 m |
| Breadth | 17.00 m |
| Depth | 4,20 m |
| Draft (approx.) | 2,00 m |
| Dredging depth | |
| as cutter dredger | 22 and 38 m |
| as deep suction dredger | 45 m |
| Suction pipe diameter | 750 mm |
| Discharge pipe diameter | 700 mm |
| Cutter power | 1 x 1.000 kW |
| Inboard dredge pumps | 2 x 1.825 kW |
| Submerged dredge pump | 1x 1.250 kW |
| Dredge pump drives | 2 x Cat 3516 B, 1.825 kW each |
| Under water pump drive | 1 x Cat 3512 B , 1.060 kW |
| Total installed power (approx.) | 6.800 kW |
Please inquire for more details
