26 x 11 Multi-purpose Utility Vessel
Versatile workboats, Dredging support, Diving support, Cable repair, Supply, Anchor handling
2003, GL. l x w x d (m): 26.00 x 11.00 x 3.25, deadweight 250 ton, propulsion 2 x Cat 3412, bollard pull 14 tons. Knuckle boom crane, anchor winch, bow & stern roller. Accommodation for 4 crew. Location: Netherlands. Price: Inquire
| GENERAL | |
| Year Built | 2003 |
| Classification | DNV-GL, + 100 A5 + MC |
| DIMENSIONS | |
| Length oa | 26.00 m |
| Length bpp | 24.96 m |
| Beam | 11.00 m |
| Depth Mld | 3.25 m |
| Draft | 2.50 m |
| GRT | 220 |
| Deadweight | 250 t |
| PERFORMANCE | |
| Bollard Pull | 14 t |
| Speed, free running | ≈ 9.0 Knots |
| TANK & PUMP CAPACITY | |
| Fuel oil, transfer pump | 158 m3, 1 x 20m³ / hr at 15 m head |
| Fresh Water | 83 m3 |
| MACHINERY | |
| Main Engine | 2 x Caterpillar 3412TA, 537 kW |
| Generator | 2 x Perkins 80 kW each |
| Gear Box | 2 x Reintjes 363 Reverse / Reduction ratio 4.92:1 |
| Propeller | 2 x Fixed Pitch, 4 -Blade, dia. 1400mm |
| DECK EQUIPMENT | |
| AH / Towing Winch | 1 x 100 ton, 5 m/min. Brake holding 80 tons, 500 m x 70 mm |
| Towing Hook | 20 tons SWL |
| Roller | 2 x at Bow and Stern, dia 600mm |
| Anchor Windlass | 1 x 3 t x 10 m/min. pull |
| Capstan | 2 x 3 tons, 15 m/min. |
| Deck Crane | 1 x Heila HLRM 140-3s, 120 tm, max. reach 12.25 m |
| OTHER EQUIPMENT | |
| Navigation | Magnetic Compass, Echo Sounder. Radar, GPS, EPIRB , etc. |
| Communication | VHF, SSB |
| Life Saving | 2 x 10 Men Inflatable Life Raft. 8 Life Buoy, 14 Life-Jackets |
| ACCOMMODATION | 4 berth, fully air-conditioned |
